USE AND CARE GUIDE
RYDEN ELECTRIC FIREPLACE MEDIA MANTEL
QUESTIONS, PROBLEMS, MISSING PARTS? BEFORE RETURNING TO THE STORE,
CALL HOME DECORATORS COLLECTION CUSTOMER SERVICE
MONDAY - FRIDAY 8 A.M. - 7 P.M. EST, AND SATURDAY 9 A.M. - 6 P.M. EST.
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators through the purchase of this electric fireplace. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Home Decorators!
Advertisement
Table of Contents
Related Manuals for Home Decorators Collection 1006152672
Summary of Contents for Home Decorators Collection 1006152672
- Page 1 USE AND CARE GUIDE RYDEN ELECTRIC FIREPLACE MEDIA MANTEL QUESTIONS, PROBLEMS, MISSING PARTS? BEFORE RETURNING TO THE STORE, CALL HOME DECORATORS COLLECTION CUSTOMER SERVICE MONDAY - FRIDAY 8 A.M. - 7 P.M. EST, AND SATURDAY 9 A.M. - 6 P.M. EST. 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS...
-
Page 2: Table Of Contents
Table of Contents Maximum Load Warning ........... 2 Package Contents ..............7 Safety Information ............. 3 Assembly ..............8 Warranty ..............5 Operation ..............17 Pre-Assembly ............. 6 FCC/IC Information ............20 Hardware Included ........... 6 Care & Cleaning ............20 Product Specifications ............ -
Page 3: Safety Information
Safety Information Please read and understand this entire manual before attempting to assemble, operate or install the product. If you have any question regarding the product, please call customer service at 1-800-986-3460, Monday-Friday 8 A.M. - 7 P.M. EST, WARNING: Under no circumstances should this fireplace be and Saturday 9 A.M. - Page 4 Safety Information (continued) NOTE: Use care in assembling your new fireplace. Take your time and use the hardware provided and a quality Phillips head screwdriver. Never overtighten bolts. • Do not sit on any part of the mantel. NOTE: To avoid injury from unexpected starting or electrical shock, do not plug the power cord into a source of power during unpacking and assembly.
-
Page 5: Warranty
Warranty Warranty 1 Year Limited Warranty: The manufacturer warrants that your new Electric Fireplace is free from manufacturing and material defects for a period of one year from date of purchase, subject to the following conditions and limitations. Install and operate this appliance in accordance with the installation and operating instructions furnished with the product at all times. -
Page 6: Pre-Assembly
Pre-Assembly HARDWARE INCLUDED Part Description Part Number Quantity Screw 4 x 50 mm PH-SCRBLK006 Screw 3 x 12 mm PH-SCRBLK004 USB output P23MMP549-CC Screw 3 x 15 mm PH-SCRBLK010 Magnetic Catch PH-MCHBRW001 Back Panel Bracket PH-BKTBLK017 Screw 3 x 15 mm P23MMP549-GG Screw 3 x 12 mm PH-SCRBLK007... -
Page 7: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS NOTE: All panels are labeled left and right as viewed from the front of unit. Part Description Quantity Bottom Shelf Left Partition Right Partition Center Shelf Left Side Panel Right Side Panel Top Panel Back Panels Upper Back Panel Cabinet Door Cabinet Door... -
Page 8: Assembly
Assembly Attaching the center assembly Locate the Center Shelf (D) and the Left and Right Partitions (B and C). Align the Center Shelf (D) between the Left and Right Partitions (B and C). Push together, inserting the pre-installed screws on the Center Shelf (D) into the holes on the Left and Right Partitions (B and D) as shown. Tighten the fasteners on the Left and Right Partitions (B and C) using a Phillips Screwdriver. - Page 9 Assembly (continued) Attaching the side panels Locate the Left and Right Side Panels (E and F). Align the Left and Right Side Panels (E and F) with the Bottom Shelf (A). Insert Screws (AA) through the Bottom Shelf (A) and into the pre-drilled holes on the edges of the Left and Right Side Panels (E and F) as shown.
- Page 10 Assembly (continued) Attaching the back panels Locate the Back Panels (H) and the Upper Back Panel (I). Slide the Back Panels (H) into the grooves between the center partitions and the outer side panels as shown. Slide all the way down until the Back Panels (H) meet the bottom shelf.
- Page 11 Assembly (continued) Attaching the cabinet doors Lift the Cabinet Door (J) and align the hinges with the pre-attached hardware on the main assembly as shown. Slide the barrel of the hinge on the door downward onto the pin of the hardware on the main assembly. Repeat steps with Cabinet Door (K).
- Page 12 Assembly (continued) Attaching the top panel Place the Top Panel (G) on top of the main assembly while aligning the pre-installed screws with the screw holes on the edges of the main assembly. After inserting the screws into the holes, tighten the fasteners from underneath the Top Panel (G) using a Phillips Screwdriver as shown.
- Page 13 Assembly (continued) Securing the surround brackets Find the pre-attached metal plate bracket behind the top surround rail. Rotate the bracket to span the joint of the top surround rail and side surround rail. Secure the surround bracket with a Screw (HH). Repeat to secure both sides.
- Page 14 Assembly (continued) Inserting the adjustable shelves Locate the four Adjustable Shelves (L). Insert the Shelf Pins (KK) into the pre-drilled holes on the inside of each cabinet side panel at your desired height. Align all Shelf Pins (KK) to the same height to ensure your shelf is level.
- Page 15 Assembly (continued) Securing the fireplace insert Align the Metal Brackets (MM) behind the Fireplace Insert (M) and above the pre-drilled holes. Secure with the Mounting Screws (LL) on both sides. Adjusting the levelers In order for the doors on your unit to work properly, your unit must be level. Pre-attached levelers are located under the bottom panel of the unit.
- Page 16 Assembly (continued) Installing the tip restraint hardware When the Tipping Restraint Hardware (NN) is properly installed, it can provide protection against unexpected tipping of the Unit due to small tremors, bumps or Wall climbing. Each Tipping Restraint Hardware (NN) includes one Unit Anchor, one Wall Anchor, one Anchor Tether, and four Anchor Screws.
-
Page 17: Operation
Operation Operation NOTE: The control panel can be accessed at the upper-right corner of the insert. Powering the fireplace Adjusting the flame Push the Power button to supply power to all There are 5 unique 3D flame colors that can be selected. functions of the fireplace and put the insert in a 1: Spectrafire ®... - Page 18 Operation (continued) Adjust the fan speed Fan oscillation Pressing this button will turn on or off the oscillation Press the Fan button in succession to cycle through feature. When on, the louvers will oscillate back and the speed settings; 1 (lowest speed) 2 (middle speed) forth to distribute the air flow to a wider area.
- Page 19 Operation (continued) Power cord information This heater is for use on 120 volts. The cord has a plug as shown in the figure. Connect to properly grounded outlets only. Do not use a two-prong adapter. Never use with an extension cord or relocatable power tap (outlet/ power strip).
-
Page 20: Fcc/Ic Information
FCC/IC Information WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 21: Troubleshooting
Troubleshooting PROBLEM ROOT CAUSE CORRECTIVE ACTION Fireplace has reached set temperature. Fireplace stopped heating before Set the fireplace to a higher temperature or Temperature around fireplace might be a few reached desired temperature. always “on”. degrees higher than other area in the room. Unplug the fireplace, remove the back panel of the fireplace and check that the The thermostat sensor is... - Page 22 Troubleshooting (continued) PROBLEM ROOT CAUSE CORRECTIVE ACTION Flame effect works but heater With the power on press and hold the Power function does not and the emberbed button on the control panel for 10 seconds. The heater is disabled. flashes when the Heater button is Once re-enabled the emberbed lights will pressed.
-
Page 23: Replacement Parts
Replacement Parts For replacement parts, call our customer service department at 1-800-986-3460, MONDAY - FRIDAY 8 A.M. - 7 P.M. EST, AND SATURDAY 9 A.M. - 6 P.M. EST. Part Description Qty. Ember bed with Log Set Flame Generator Drive Motor Flame Circuit Board Control Panel Circuit Board PCB Binboard... - Page 24 Questions, problems, missing parts? Before returning to the store call Home Decorators Customer Service Monday - Friday 8 A.M. - 7 P.M. EST, and Saturday 9 A.M. - 6 P.M. EST. 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS RETAIN THIS MANUAL FOR FUTURE USE.
