INSTALLATION MANUAL
Parts List
1
Bull bar
2
Driver / left
mounting bracket
2
Passenger / right
mounting bracket
4
Hex bolt, M8
4
Flat washer, M8
4
Nylock nut, M8
4
Hex bolt, M10
8
Flat washer, M10
4
Nylock nut, M10
4
Bolt plate, M12
4
Flat washer, M12
4
Nylock nut, M12
1*
LED wiring harness*
* Wiring harness only included
with LED equipped models
Tools Required
Ratchet
Extension
Level
Wrench, 18mm
Socket, 13mm
Socket, 16mm
Socket, 17mm
Socket, 18mm
Socket, 19mm
Torque Specifications
M6 bolt
3 ft.-lbs.
M8 bolt
7 ft.-lbs.
M10 bolt
16 ft.-lbs.
M12 bolt
28 ft.-lbs.
1/4" bolt
3 ft.-lbs.
5/16" bolt
7 ft.-lbs.
3/8" bolt
16 ft.-lbs.
7/16" bolt
20 ft.-lbs.
1/2" bolt
28 ft.-lbs.
Level of Difficulty
Easy
Product Image
2154001
2154101
Notes and Maintenance
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
For chrome powder coat, polish may be used to clear small scratches
and scuffs on the finish. Mild soap may be used also to clean the product.
For black finishes, mild soap may be used to clean the product.
Refer to the table to the left when securing hardware during the
installation process to help prevent damage to the product or vehicle.
PAGE 1 • RC • 877.287.8634 • NEED ASSISTANCE?
Scan
for helpful
install tips
2164001
2164101
• ARIESAUTOMOTIVE.COM
Advertisement
Table of Contents
Related Manuals for Aries 2154001
Summary of Contents for Aries 2154001
- Page 1 Hex bolt, M8 Flat washer, M8 Nylock nut, M8 Hex bolt, M10 Flat washer, M10 Nylock nut, M10 Bolt plate, M12 2154001 2164001 Flat washer, M12 Nylock nut, M12 LED wiring harness* * Wiring harness only included with LED equipped models...
- Page 2 Step 1A - Vehicles without tow hooks For vehicles with tow hooks, skip to Step 2. Locate the two mounting points on the front end of the vehicle. Locate the passenger-side mounting point. Step 1B - Vehicles without tow hooks Place the passenger-side mounting bracket up to the frame of the vehicle.
- Page 3 Step 4 Place the driver-side bracket over the bolts and secure the bracket to the bull bar using two M8 flat washers and M8 nylock nuts. Snug the hardware, but do not fully tighten. Repeat this step for the passenger-side bracket. Step 5 With help, lift the bull bar into place and align the mounting tabs on the...
- Page 4 Test the lights to ensure proper function. Step 9 Congratulations on the installation of your new ARIES AdvantEDGE bull bar. ™ With the bull bar installed, periodic inspections should be performed to ensure all mounting hardware remains tight.
