MEITRACK TC68L/TC68SL Plug-and-Play Vehicle GPS Tracker User Guide

3 Product Introduction

3.1 Product Overview

The TC68L/TC68SL is a plug-and-play vehicle GPS tracker equipped with an OBD II plug, which supports vehicle
positioning, live tracking, and anti-theft functions.
With a standard OBD II plug, it can be easily installed. The device has an internal battery that supplies power to it for
a limited time period. When the device is removed, an instant alert will be received.
The TC68L/TC68SL tracker is a perfect choice for private cars and other motor vehicles equipped with an OBD II
connector.
The TC68L tracker supports the OBD function, while the TC68SL tracker does not support this function.

3.2 Product Specifications

Item
Dimension
Weight
Power supply
Backup battery
Battery life
Power consumption
Operating
temperature
Operating humidity
LED indicator
Button/Switch
Memory
Sensor
Frequency band
GPS sensitivity
Positioning accuracy
I/O port
WiFi function
(optional)
Copyright © 2019 Meitrack Group All rights reserved.
Specifications
67 mm x 51 mm x 23.5 mm
60g
DC 11.5–36 V / 1 A
110 mAh/3.7 V
Power-saving mode: 12 hours
Normal working mode: 1 hour
Current in standby mode: 100 mA
-20°C to 55°C
5%–95%
2 LED indicators showing GSM and GPS status
1 SOS button
8 MB
3-axis accelerometer
E version
GSM 900/1800 MHz
WCDMA B1/B5/B8
FDD B1/B3/B5/B7/
B8/B20
TDD B38/B40/B41
-161 dB
2.5 meters
1 USB port
2.4 GHz WiFi hotspot
A version J version
N/A N/A
B2/B4/B5 B1/B6/B8/B19
B2/B4/B12 B1/B3/B8/B18
/B19/B26
N/A B41
AU version
850/900/1800/
1900 MHz
B1/B2/B5/B8
B1/B2/B3/B4/B
5/B7/B8/B28
B40
