- Page 1 Garmin Navigator User Guide Garmin Navigator User Guide Applicable Model: T622...
-
Page 2: Change History
File Name Garmin Navigator User Guide Created By William Sun Project T622 Creation Date 2015-07-30 Update Date 2016-02-03 Subproject Accessory User Guide Total Pages Version V1.0 Confidential External Documentation Copyright © 2016 Meitrack Group All rights reserved. - 2 -... -
Page 3: Table Of Contents
2.1 Product Function ................................- 4 - 2.2 Specifications ..................................- 4 - 3 Main Device and Accessory ................................- 4 - 4 Connecting the Garmin Navigator to the T622 ..........................- 4 - 5 Occupied Resource ..................................- 5 - 6 Configuring the T622 ..................................- 6 - 6.1 Setting the Serial Port by Meitrack Manager ........................- 6 -... -
Page 4: Copyright And Disclaimer
The user manual may be changed without notice. Without prior written consent of Meitrack Group, this user manual, or any part thereof, may not be reproduced for any purpose whatsoever, or transmitted in any form, either electronically or mechanically, including photocopying and recording. -
Page 5: Occupied Resource
Serial port 1 Serial port 2 Figure: Connecting the Garmin navigator to the tracker Plug the Garmin navigator data wire (RS232) into T622's dedicated port (RS232 or RS232/RS485). 5 Occupied Resource T622: RS232 port or RS232/RS485 port Copyright © 2016 Meitrack Group All rights reserved. -
Page 6: Configuring The T622
Garmin Navigator User Guide 6 Configuring the T622 6.1 Setting the Serial Port by Meitrack Manager Please select corresponding port according to the physical port. In this example, use serial port 2. On the Device page, set SerialPort 2 to GARMIN Navascreen. -
Page 7: Sending Messages From The Garmin Navigator - D75
X5: indicates the serial port number of the Garmin navigator. X5 = 1: serial port 1; X5 = 2: serial port 2. Applicable Model T622 Example GPRS Sending @@n85,866699027509340,D76,30245BED,8,0191E7B6,0046005300440046005300460 04400530046,2*B6\r\n GPRS Reply $$n28,866699027509340,D76,OK*33\r\n Copyright © 2016 Meitrack Group All rights reserved. - 7 -... -
Page 8: Obtaining Garmin Navigator Info - D77
Visit http://ms03.trackingmate.com, enter the user name and password, and log in to the MS03. (Purchase the login account from your provider.) Make sure the device IP address has been set to 67.203.15.7 and port to 10003. Select the tracker, and choose Send command. Copyright © 2016 Meitrack Group All rights reserved. - 8 -... - Page 9 From the pop-up information box, select Send Message to Garmin from Command, set Message and Serial NO., and click Send command. The platform will communicate with the Garmin navigator. Copyright © 2016 Meitrack Group All rights reserved. - 9 -...
-
Page 10: Sending The Destination To The Garmin Navigator
On the Garmin navigator, you will see the route planning. 8.3 Obtaining Garmin Navigator Info On the following window, select Get GARMIN navigation information from Command, set Serial NO., and click Send command. Copyright © 2016 Meitrack Group All rights reserved. - 10 -... - Page 11 The following prompt will be displayed. Note: This function is available only when the Garmin navigator is working. If you have any questions, do not hesitate to email us at info@meitrack.com. Copyright © 2016 Meitrack Group All rights reserved. - 11 -...
