Teltonika FMM130 Quick Manual
Advanced cat m1/gsm/gnss/ble terminal with flexible inputs configuration
Hide thumbs
Also See for FMM130:
- How-to (2 pages) ,
- First start-up quick start manual (9 pages) ,
- How-to (5 pages)
Related Manuals for Teltonika FMM130
Summary of Contents for Teltonika FMM130
- Page 1 FMM130 Quick Manual Advanced CAT M1/GSM/GNSS/BLE terminal v1.5 with flexible inputs configuration...
-
Page 2: Table Of Contents
How to install USB drivers (Windows) ............7 Configuration (Windows) ................... 7 Quick SMS configuration..................9 Mounting recommendations ............. 10 LED indications ..................11 Characteristics ..................11 Basic characteristics ................11 Electrical characteristics ..................12 Safety information ................14 Certification and Approvals ............... 15 FMM130 | Wiki... -
Page 3: Know Your Device
Know your device Figure 1 FMM130 device view FMM130 | Wiki... -
Page 4: Pinout
Pinout Table 1 FMM130 2x6 socket pinout PIN NUMBER PIN NAME DESCRIPTION VCC (10-30)V DC (+) Power supply (+10-30 V DC). Digital output, channel 3. Open collector DOUT 3 output. Max. 0,5 A DC. Analog input, channel 2. Input range: 0- DIN 3 / AIN 2 30 V DC / Digital input, channel 3. -
Page 5: Wiring Scheme
Wiring scheme Figure 3 FMM130 Wiring scheme Automotive relay FMM130 | Wiki... -
Page 6: Set Up Your Device
Set up your device How to insert Micro-SIM card and connect the battery 1. Gently remove FMM130 bottom cover using plastic pry tool from both sides. Then remove the top cover. 2. Insert Micro-SIM card as shown with PIN request disabled or... -
Page 7: Pc Connection (Windows)
Setup will continue installing the driver and eventually the confirmation window will appear. Click Finish to complete the setup. 1. Power-up FMM130 with DC voltage (10 – 30 V) power supply Configuration (Windows) using supplied power cable. LED’s should start blinking, see “LED indications”. - Page 8 Most important configurator section is GPRS – where all your server GPRS settings can be configured and Data Acquisition – where data acquiring parameters can be configured. More details about FMM130 configuration using Configurator can be found in our Wiki. Figure 10 Configurator Status window FMM130 | Wiki...
-
Page 9: Quick Sms Configuration
120 Server settings: seconds 2004 – Domain • After successful SMS configuration, FMM130 device will synchronize 2005 – Port • time and update records to configured server. Time intervals and 2006 – Data sending protocol (0 •... -
Page 10: Mounting Recommendations
▬ When the module is connected, measure the voltage again to make sure it did not decrease. ▬ It is recommended to connect to the main power cable in the fuse box. ▬ 3 A, 125 V external fuse shall be used. FMM130 | Wiki... -
Page 11: Led Indications
Basic characteristics Table 5 Basic characteristics Table 3 Navigation LED indications MODULE BEHAVIOUR MEANING Name Quectel BG96, Teltonika TM2500 Permanently switched on GNSS signal is not received LTE CAT M1/NB- Blinking every second Normal mode, GNSS is working Technology IoT/GSM/GPRS/GNSS/BLUETOOTH... -
Page 12: Electrical Characteristics
Voltage, Engine RPM (CAN Adapters, OBDII PHYSICAL SPECIFICATION dongle) Dimensions 65 x 56 x 20,6 mm (L x W x H) Weight 55 g Electrical characteristics OPERATING ENVIRONMENT Operating temperature (without -40 °C to +85 °C battery) FMM130 | Wiki... - Page 13 Input voltage (Recommended Operating Supply NEGATIVE INPUT Conditions) voltage Input resistance 38.45 kΩ Input Voltage threshold (DIN1) Input voltage (Recommended Operating Supply Conditions) voltage Input Voltage threshold (DIN2) Input voltage threshold Input Voltage threshold (DIN3) Sink current ANALOG INPUT FMM130 | Wiki...
-
Page 14: Safety Information
All related devices instructions. must meet the requirements of EN 60950-1 standard. The device FMM130 is not designed as a navigational device for boats. Battery should not be disposed of with general household waste. Bring damaged or worn-out batteries to your local Do not disassemble the device. -
Page 15: Certification And Approvals
• FMM130 E-Mark • FMM130 RoHS • FMM130 Declaration of device operation temperature • This sign on the package means that it is necessary to read the User‘s Manual before your start using the device. Full User‘s Manual version can be found in our Wiki. -
Page 16: Warranty
More information can be found at teltonika.lt/warranty-repair • Repaired • Replaced with a new product • Replaced with an equivalent repaired product fulfilling the same functionality • TELTONIKA can also repair products that are out of warranty at an agreed cost. FMM130 | Wiki...
