  • Page 1 FMC640 Quick Manual Professional LTE/GNSS v1.6 terminal...

  • Page 2: Table Of Contents

    How to install USB drivers (Windows) ..........7 Configuration (Windows) ..............7 Quick SMS configuration ..............9 Mounting recommendations ............. 10 LED indications ................11 Characteristics................11 Basic characteristics ............... 11 Electrical characteristics ..............13 Safety information ..............14 Certification and Approvals ............15 FMC640| Wiki...

  • Page 3: Know Your Device

    Know your device Figure 1 FMC640 device view FMC640| Wiki...

  • Page 4: Pinout

    Data channel for Dallas 1-Wire® devices DIN3 Digital input, channel 3 Digital input, channel 1. DEDICATED FOR IGN (DIN1) IGNITION INPUT Figure 2 FMC640 pinout CAN 2H SAE J1939 CAN interface High channel 2 Analog input, channel 1. Input range: 0-30V/0- AIN1 10V DC Digital output.

  • Page 5: Wiring Scheme

    Wiring scheme Figure 3 FMC640 Wiring scheme Automotive relay FMC640| Wiki...

  • Page 6: Set Up Your Device

    5. After configuration, see “PC Connection (Windows)”, attach device cover back. Figure 6 SIM card insert Figure 7 Battery connection 6. Screw in all screws. Device is ready to be mounted. Figure 9 Device is ready Figure 8 Attaching cover back FMC640| Wiki...

  • Page 7: Pc Connection (Windows)

    PC Connection (Windows) Configuration (Windows) 1. Power-up FMC640 with DC voltage (10 – 30 V) power supply At first FMC640 device will have default factory settings set. These using power wires. LED’s should start blinking, see “LED settings should be changed according to the user's needs. Main indications”.
  • Page 8 Most important configurator section is GPRS – where all your server and GPRS settings can be configured and Data Acquisition – where data acquiring parameters can be configured. More details about FMC640 configuration using Configurator can be found in our Wiki. Figure 12 Configurator Status window FMC640| Wiki...

  • Page 9: Quick Sms Configuration

    2005 – Port • 2006 – Data sending protocol • After successful SMS configuration, FMC640 device will (0 – TCP, 1 – UDP) synchronize time and update records to configured server. Time intervals and default I/O elements can be changed by using Teltonika Configurator parameters.

  • Page 10: Mounting Recommendations

    ▬ Use 3A, 125V external fuse. and dynamic potentials on the line GND will be unpredictable, which can lead to unstable FMC640 operation and even its failure. FMC640| Wiki...

  • Page 11: Led Indications

    Device is not working or Device is in 4G bands EC91-EX: LTE FDD: B1/B3/B7/B8/B20/B28 boot mode LTE: LTE FDD: Max 10Mbps (DL)/Max 5Mbps (UL) UMTS: WCDMA: Max 384Kbps (DL)/Max 384Kbps Data transfer (UL) GSM: GPRS: Max 107Kbps (DL)/Max 85.6Kbps (UL) Data support SMS (text/data) FMC640| Wiki...
  • Page 12 2MB internal flash memory and external SD card Memory Battery Discharge temperature = 20 ± 5 ℃ (Ambient Temp.) up to 32 GB. Battery storage temperature -20 °C to +45° C Operating humidity 5% to 95% non-condensing Ingress Protection Rating IP41 FMC640| Wiki...

  • Page 13: Electrical Characteristics

    Internal terminal resistors CAN bus Ω Input resistance (DIN3) kΩ Differential input resistance kΩ kΩ Input resistance (DIN4) Recessive output voltage Input voltage (Recommended Operating Supply Differential output voltage voltage Conditions) Common mode input voltage Input Voltage threshold (DIN1, DIN2, DIN3, DIN4) FMC640| Wiki...

  • Page 14: Safety Information

    All related devices storm is prohibited. must meet the requirements of EN 62368-1 standard. The device FMC640 is not designed as a navigational device for • boats. The device is susceptible to water and humidity.

  • Page 15: Certification And Approvals

    • FMC640 Declaration of IMEI assignment • • FMC640 Declaration of device operation temperature This sign on the package means that it is necessary to read the User‘s Manual before your start using the device. Full User‘s Manual version can be found in our Wiki.

  • Page 16: Warranty

    More information can be found at teltonika-iot- • Repaired group.com/warranty-repair/ • Replaced with a new product • Replaced with an equivalent repaired product fulfilling the same functionality • TELTONIKA can also repair products that are out of warranty at an agreed cost. FMC640| Wiki...
