  • Page 1 FMM125 Quick Manual Advanced CATM1/GSM/GNSS/BLE v1.5 terminal with internal antennas, RS485 and RS232 interfaces...

  • Page 2: Table Of Contents

    How to install USB drivers (Windows) ............7 Configuration (Windows) ................... 7 Quick SMS configuration..................9 Mounting recommendations ............. 10 LED indications ..................11 Characteristics ..................11 Basic characteristics .................... 11 Electrical characteristics ..................13 Safety information ................14 FMM125 | Wiki...

  • Page 3: Know Your Device

    Know your device Figure 1 FMM125 device view FMM125 | Wiki...

  • Page 4: Pinout

    Pinout Table 1 FMM125 2x6 socket pinout Pin number Pin name Description VCC (10-30)V DC (+) Power supply (+10-30 V DC). Analog input, channel 1. Input range: 0- AIN 1/ DIN 2 30 V DC / Digital input, channel 2.

  • Page 5: Wiring Scheme

    Wiring scheme Figure 3 FMM125 Wiring scheme Automotive relay FMM125 | Wiki...

  • Page 6: Set Up Your Device

    Set up your device How to insert SIM card and connect the battery 1. Gently remove FMM125 cover using plastic pry tool from both sides. 2. Insert SIM card as shown with PIN request disabled or read our Wiki how to enter it later in Teltonika Configurator.

  • Page 7: Pc Connection (Windows)

    Setup will continue installing the driver and eventually the confirmation window will appear. Click Finish to complete the setup. 1. Power-up FMM125 with DC voltage (10 – 30 V) power supply Configuration (Windows) using supplied power cable. LED’s should start blinking, see “LED indications”.
  • Page 8 Most important configurator section is GPRS – where all your server GPRS settings can be configured and Data Acquisition – where data acquiring parameters can be configured. More details about FMM125 configuration using Configurator can be found in our Wiki. Figure 10 Configurator Status window FMM125 | Wiki...

  • Page 9: Quick Sms Configuration

    120 Server settings: seconds 2004 – Domain • After successful SMS configuration, FMM125 device will synchronize 2005 – Port • time and update records to configured server. Time intervals and 2006 – Data sending protocol (0 •...

  • Page 10: Mounting Recommendations

    ▬ When the module is connected, measure the voltage again to make sure it did not decrease. ▬ It is recommended to connect to the main power cable in the fuse box. ▬ 3 A, 125 V external fuse shall be used. FMM125 | Wiki...

  • Page 11: Led Indications

    Basic characteristics Table 5 Basic characteristics Table 3 Navigation LED indications Module Behaviour Meaning Name Quectel BG96, Teltonika TM2500 Permanently switched on GNSS signal is not received Technology LTE CAT M1/NB-IoT/GSM/GPRS/GNSS/BLUETOOTH Blinking every second Normal mode, GNSS is working GNSS is turned off because:...
  • Page 12 Log Mode, NMEA, LLS, LCD, RFIH HID/MF7, Garmin RS232 Physical specification FMI, TCP SCII/Binary Dimensions 65 x 56,6 x 20,6 mm (L x W x H) RS485 Log Mode, NMEA, LLS, TCP SCII/Binary Weight 55 g Operating environment FMM125 | Wiki...

  • Page 13: Electrical Characteristics

    Input voltage (Recommended Operating Supply Supply voltage +4.5 +4.7 Conditions) voltage Output inner resistance Ω Input Voltage threshold (DIN 1) Output current (U > 3.0 V) Input Voltage threshold (DIN 2) Short circuit current (U = 0) FMM125 | Wiki...

  • Page 14: Safety Information

    EN 60950-1 standard. Battery should not be disposed of with general The device FMM125 is not designed as a navigational device for boats. household waste. Bring damaged or worn-out batteries to your local recycling center or dispose Do not disassemble the device.
  • Page 15 • FMM125 E-Mark • FMM125 RoHS • FMM125 Declaration of device operation temperature • This sign on the package means that it is necessary to read the User‘s Manual before your start using the device. Full User‘s Manual version can be found in our Wiki.

  • Page 16: Warranty

    More information can be found at teltonika.lt/warranty-repair • Repaired • Replaced with a new product • Replaced with an equivalent repaired product fulfilling the same functionality • TELTONIKA can also repair products that are out of warranty at an agreed cost. FMM125 | Wiki...
