Pyronix Castle EURO 162 Installation Reference page 8

1.3.2 EURO 280 Input Mapping Table:
DEVICES
EURO 280 PCB
EURO-ZEM8 / EURO-ZEM8+/ EURO-ZEM8+PSU / EURO-ZEM32-WE
EURO-ZEM8 / EURO-ZEM8+/ EURO-ZEM8+PSU
EURO-LCD
EURO-LCD / EURO-PROXI*
Total
NOTE 1: 3 x EURO-ZEM32-WE can be connected to the EURO 280. This expander allows 32 inputs
which are separated into 4 addresses (each address enables 8 wireless inputs). It is possible to mix
the wired and wireless remote expanders.
When installing a EURO-ZEM32-WE, the first wireless expander will learn the 32 wireless keyfobs
and 2 wireless sounders. If this expander is disconnected, the keyfobs and sounders will need to be
learnt on another expander again.
*NOTE 2: If the EURO-PROXI (Internal Tag Reader) is programmed as an 'Set/Unset' device, 2
inputs are can be programmed. If the EURO-PROXI is programmed as 'Entry Control' or 'Access
Control' only 1 input can be programmed.
EURO 162/280 Installation Manual
Page: 8
Address Input Numbers
PCB 1-8
0 9-16
1 17-24
2 25-32
3 33-40
4 41-48
5 49-56
6 57-64
7 65-72
8 73-80
9 81-88
10 89-96
11 97-104
12 105-112
13 113-120
14 121-128
15 129-136
16 137-144
145-152
17
153-160
18
161-168
19
169-176
20
177-184
21
185-192
22
193-200
23
201-208
24
209-216
25
217-224
26
225-232
27
233-240
28
241-248
29
249-250
0
251-252
1
2 253-254
3 255-256
4 257-258
5 259-260
6 261-262
7 263-264
8 265-266
9 267-268
10 269-270
11 271-272
12 273-274
13 275-276
14 277-278
15 279-280
280
