LEDS

Transmit (green)
Receive (yellow)
Power (blue)
Diagnostic (yellow)
Speed (yellow)
Activity (green)
8
Q u i c k S t a r t G u i d e
MEANING
Blinking = EDS is transmitting data on the serial port.
Blinking = EDS is receiving data on the serial port.
ON = EDS is receiving power.
Fast blink = initial startup (loading OS).
Slow blink (once per second) = operating system startup.
ON = unit has finished booting.
ON = EDS is connected to a 100 Mbps Fast
Ethernet network.
OFF = EDS is connected to a 10 Mbps Ethernet network.
Blink = EDS is sending data to or receiving data from the
Ethernet network.
