QUICK CONNECT

Complete the following steps in order. Refer to the numbers in the
figure below.
1. Connect a serial device to your unit.
2. Connect an Ethernet cable to the RJ45 port.
3. Supply power to your unit using the power cord that was included in
the packaging.
4. Supply power to the serial device.
1
Serial Device
2
10/100 BASE-T
Ethernet
3
3
