Introduction

Thank you for the purchase of the USB Video Capture Device.
Applying state of the art technology, the USB Video Capture
Device attached through either RCA jack or S-Video to a
camcorder, VCR, DVD allowing the user to perform basic features
of a USB grabber and comes with a snapshot button to capture
images for multimedia applications. It can be used with any PC
with Windows OS and comes bundled with a full line of software
for video and image editing functions.
System Requir ement
Pentium 133 or above CPU, Pentium II 350 recommended
32 MB of system RAM
One USB port
Microsoft Windows 98 or above
20MB hard disk space

USB Video Capture Device Diagram

S-Video
Connector
Composite RCA Connector
Snapshot Button
USB Connector
1
