Ph Test Procedure - eXact Chlorine Plus Instruction Manual

PH7
REMOVE STRIP
1
Remove one (1) eXact
beginning the test. Set the strip in a dry, convenient place and recap the bottle immediately.
TURN METER ON
2
Press the ZERO/ON button to power the meter on; the display will show all annunciators, then
the current MENU selection, followed by the last reading.
SELECT TEST: PH7
3
Press and re-press the MENU button until the display shows the parameter PH7.
FILL METER WITH SAMPLE
4
Rinse the CELL at least 3 times with the water sample you will be testing - rinsing minimizes
the water sample.
ZERO METER
5
Press the ZERO/ON button. The cursor will move across the display, followed by 0.00 pH.
The sample is ready for testing.
DIP STRIP AND PRESS "READ"
6
Dip the eXact
This starts the 20 SECOND countdown timer. During this time move the strip in a gentle back
and forth motion (approx. 2 strokes/sec). Remove and discard the strip after "1" on the display
disappears. The cursor will move across the display while the meter prepares to measure the
sample. Record result displayed (this result is automatically stored in PH7). After testing is
completed, rinse cell immediately.
Total Chlorine High Test Procedure
HR8
NOTE: This test is good for all water temperatures 0°C - 40°C (32°F - 104°F).
REMOVE STRIP
1
Remove one (1) eXact
beginning the test. Set the strip in a dry, convenient place and recap the bottle immediately.
TURN METER ON
2
Press the ZERO/ON button to power the meter on; the display will show all annunciators, then
the current MENU selection, followed by the last reading.
SELECT TEST: HR8
3
Press and re-press the MENU button until the display shows the parameter HR8.
FILL METER WITH SAMPLE
4
Rinse the CELL at least 3 times with the water sample you will be testing - rinsing minimizes
the water sample.
ZERO METER
5
Press the ZERO/ON button. The cursor will move across the display, followed by 0.00 PPM.
The sample is ready for testing.
DIP STRIP -
6
®
Dip the eXact
This starts the 20 SECOND countdown timer. During this time move the strip in a gentle back
and forth motion (approx. 2 strokes/sec). Remove and discard the strip after "1" on the display
disappears. The meter will begin counting up for 120 seconds, at the end of which, the cursor will
move across the display while the meter prepares to measure the sample. Record result displayed
(this result is automatically stored in HR8). After testing is completed, rinse cell immediately.
*NOTE:
*NOTE: When testing outdoors (sunlight), for best accuracy, use the Mixing Cap/Cell Cover when Zeroing and Reading the sample.

pH Test Procedure

®
Strip Micro PH, Part No. 486639 from the bottle before
®
Strip Micro PH, Part No. 486639 into the CELL and immediately press READ.
®
Strip Micro CLH, Part No. 486672 from the bottle before
(read carefully and follow procedure closely)
Strip Micro CLH, Part No. 486672 into the CELL and immediately press READ.
9
PH
CLH
