eXact Chlorine Plus Instruction Manual page 6

DPD-4
CL1
REMOVE STRIP
1
Remove one (1) eXact
beginning the test. Set the strip in a dry, convenient place and recap the bottle immediately.
TURN METER ON
2
Press the ZERO/ON button to power the meter on; the display will show all annunciators,
then the current MENU selection, followed by the last reading.
SELECT TEST: CL1
3
Press and re-press the MENU button until the display shows the parameter CL1.
FILL METER WITH SAMPLE
4
Rinse the CELL at least 3 times with the water sample you will be testing - rinsing
capacity with the water sample.
ZERO METER*
5
Press the ZERO/ON button. The cursor will move across the display, followed by 0.00 PPM.
Sample is ready for testing.
DIP STRIP AND PRESS "READ"
6
®
Dip the eXact
This starts the 20 SECOND countdown timer. During this time move the strip in a gentle back and forth
motion (approx. 2 strokes/sec). Remove and discard the strip after "1" on the display disappears*.
The cursor will move across the display while the meter prepares to measure the sample. Record result
displayed (this result is automatically stored in CL1).
PRESS READ AGAIN
7
Press READ again and the meter will count down and display the next Total Chlorine result. If this
reading matches the previous result, then record this as Total Chlorine value (this result is stored
in CL1). After testing is completed, rinse cell immediately. Record the Total Chlorine as the highest
value the meter displayed.
Bromine DPD-1 Test Procedure
bR2
REMOVE STRIP
1
Remove one (1) eXact
beginning the test. Set the strip in a dry, convenient place and recap the bottle immediately.
TURN METER ON
2
Press the ZERO/ON button to power the meter on; the display will show all annunciators, then
the current MENU selection, followed by the last reading.
SELECT TEST: bR2
3
Press and re-press the MENU button until the display shows the parameter bR2.
FILL METER WITH SAMPLE
4
Rinse the CELL at least 3 times with the water sample you will be testing - rinsing minimizes
the water sample.
ZERO METER*
5
Press the ZERO/ON button. The cursor will move across the display, followed by 0.00 PPM.
The sample is ready for testing.
DIP STRIP AND PRESS "READ"
6
Dip the eXact ®
READ. This starts the 20 SECOND countdown timer. During this time move the strip in a gentle
back and forth motion (approx. 2 strokes/sec). Remove and discard the strip after "1" on the
display disappears*. The cursor will move across the display while the meter prepares to
measure the sample. Record result displayed (this result is stored in bR2 memory). After
testing is completed, rinse cell immediately.
*NOTE: When testing outdoors (sunlight), for best accuracy, use the Mixing Cap/Cell Cover when Zeroing and Reading the sample.
(Total Chlorine)
®
Strip Micro CL (DPD-4), Part No. 486670 from the bottle before
Strip Micro CL (DPD-4), Part No. 486670 into the CELL and immediately press READ.
®
Strip Micro bR (DPD-1), Part No. 486636 from the bottle before
Strip Micro bR (DPD-1), Part No. 486636 into the CELL and immediately press
Test Procedure
6
CL
