COOLSTART™
RS-830/RS-810
Congratulations on your choice of a Crimestopper CoolStart™ remote engine starter! This installation Handbook covers
the following models: RS-830 Remote Start & Keyless Entry System & RS-810 Basic Remote Start System only (No
Keyless entry).
DISCLAIMER:
This installation book is designed for the installer or individual with an existing understanding of automotive electrical
systems, along with the ability to test and connect wires for proper operation. To ease installation, we suggest that you
READ THIS MANUAL before beginning your installation. This book is provided as a GENERAL GUIDELINE and the
information contained herein may differ from your vehicle. Crimestopper Security Products, Inc. and its' vendors shall
not be liable for any accident resulting from the use of this product. This system is designed to be professionally
installed into a vehicle in which all systems and associated components are in perfect working condition.
TECHNICAL SUPPORT: (800) 998-6880
Monday - Friday 8:00am - 4:30pm Pacific Std. Time
Web Site: www.crimestopper.com
E-mail: tech-support@crimestopper.com
CRIMESTOPPER SECURITY PRODUCTS, INC.
1770 S. TAPO STREET, SIMI VALLEY, CA. 93063
REV A 08.2004
REMOTE ENGINE STARTING SYSTEM
INSTALLATION INSTRUCTIONS
INTRODUCTION
This device complies with FCC Rules part 15. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference that
may be received, including interference that may cause undesired
operation. The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to this equipment.
Such modification could void the user's authority to use the
equipment.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CrimeStopper COOLSTART RS-830
Summary of Contents for CrimeStopper COOLSTART RS-830
- Page 1 READ THIS MANUAL before beginning your installation. This book is provided as a GENERAL GUIDELINE and the information contained herein may differ from your vehicle. Crimestopper Security Products, Inc. and its’ vendors shall not be liable for any accident resulting from the use of this product. This system is designed to be professionally installed into a vehicle in which all systems and associated components are in perfect working condition.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Pre-Installation Considerations……….………...……...…………………………………………………………….……2 Cautions & Warnings…….…………...….……..…..…………………………………………………………….…..……3 Wiring……..…………………………..…………………………………………………………………………….…….3-6 Wiring High-Current Connector…….………………...………………………………………………………………..6-8 Power Door Lock Wiring...………………………………………….…………….……..………...……………………..9-10 Smart Tachless, Tach & Tach Finder………………………………………………..…..……...…....………11-12 Diesel Glow Plug Delay..………………….…………………………………...…………………...…..…………………13 Options Programming ………..……………………….…………………………………..…………….……………13-15 Transmitter Programming…………………………………………………….……………..……...………………….….16 2 Vehicle Operation.……………………………….……………………………………...………………….……………17 Troubleshooting “Before You Call” Section……………..…………………………..……………….………….………18 Jumper Pin, Antenna, & System Diagrams………………………………………………………..………….….……19-20 PRE-INSTALLATION CONSIDERATIONS BEFORE BEGINNING, check all vehicle manufacturer cautions and warnings regarding electrical service (AIR BAGS, ABS BRAKES, ENGINE / BODY COMPUTER AND BATTERY). -
Page 3: Cautions & Warnings
INSTALLATION CAUTIONS & WARNINGS **FOR SAFETY REASONS, DO NOT INSTALL in vehicles with MANUAL TRANSMISSIONS.** If accidentally left in gear, a remote started vehicle could become a self-propelled threat to life and property. DO NOT extend the Remote start ignition harness length. Mount the module so that main harness reaches all ignition switch wiring. - Page 4 WIRING PIN 8: YELLOW/BLACK FOR NEGATIVE IGNITION OUTPUT: (Relay and/or Module not included) ANTI-THEFT/ TRANSPONDER YELLOW/BLACK MODULE Diode isolate +12V CONSTANT if using both! 3rd IGN (If needed) IGN SW. PIN 8: YELLOW/BLACK: FOR ANTI-GRIND/STARTER DISABLE OUTPUT: (Relay not included) IGN 1 IGN 2 MOTOR...
- Page 5 WIRING PIN 7: EMPTY / NOT USED PIN 6: GREEN: (-) START ACTIVATION INPUT & TURBO TIMER INPUT See descriptions below & diagrams at right: Auxiliary Start Input (-) NEGATIVE START TRIGGER INPUT: a 1- AFTERMARKET Second Negative Ground pulse on this wire will ALARM / KEYLESS trigger a remote start or stop a remote started (Aux Channel...
-
Page 6: Wiring High-Current Connector
WIRING PIN 4: PURPLE: (+12V) BRAKE RESET Connect the Purple wire to the side of brake pedal switch that shows +12 volts ONLY when pedal is depressed. This is the wire that turns off the remote start once the driver’s key is in the Ignition and turned to the ON position. PIN 3: ORANGE/BLACK: (-) OEM DISARM OUTPUT This wire provides a Ground pulse to disarm the vehicles' Factory anti-theft system prior to a Remote Start. - Page 7 WIRING: 7-PIN HIGH-CURRENT CONNECTOR PINK: +12V IGNITION OUTPUT 40A: Connect to circuit in the vehicle that provides true Ignition Power for systems such as Spark and Fuel. Typically, this wire turns ON with the second position of the key, STAYS ON WHEN CRANKING, and continues ON as the vehicle runs.
- Page 8 WIRING: 7-PIN HIGH-CURRENT CONNECTOR 7-PIN High Current Diagram not to scale, Connector for illustration purposes only. Your vehicle may differ. PARKING LIGHTS FUSE WHITE FUSE FUSE +10A or 500mA (-) PINK/WHITE VEHICLE PINK BROWN FUEL ENGINE GRAY BATTERY PUMP STARTER COIL IGN 2 ACC 2...
-
Page 9: Power Door Lock Wiring
RS-830 ONLY: 3-PIN POWER DOOR LOCK WIRING CONNECTOR GREEN: (-) Negative pulse for LOCK Crimestopper Door Lock Accessories: CS-6600DLM: Dual-relay plug-in module for Reverse RED: +12V When using external relays (TERM 86) Polarity, Positive, or Aftermarket Motors. BLUE: (-) Negative pulse for UNLOCK... - Page 10 RS-830 ONLY: BASIC POWER DOOR LOCK DIAGRAMS NEGATIVE TRIGGER DOORLOCK WIRING POSITIVE TRIGGER DOORLOCK WIRING GREEN GREEN FUSED +12V BLUE BLUE FACTORY FACTORY POWER POWER LOCKING LOCKING RELAYS RELAYS AFTERMARKET MOTOR/DOOR LOCK WIRING REVERSE POLARITY DOOR LOCK WIRING GREEN GREEN FUSED FUSED +12V...
-
Page 11: Smart Tachless, Tach & Tach Finder
“SMART TACHLESS” MODE Your CoolStart system includes a unique voltage monitor called “Smart Tachless” mode. This mode allows this unit to efficiently start an engine without the use of a tach signal wire. These modules actively monitor the voltage level of the vehicle to control the starter motor each time a remote start is requested. - Page 12 TACH PROGRAMMING & TACH SIGNALS INTRODUCTION Tach signals will vary in levels and frequencies depending on many factors including the type of vehicle and the source of the signal. The signals from a vehicle’s injector wire and coil pac wire can vary greatly even on the same engine. The tach signal from an engine can also affected by other sources such as electronic noise from the ignition or computer modules.
-
Page 13: Diesel Glow Plug Delay
DIESEL GLOW PLUG DELAY This feature provides a solution for diesel vehicles that require a delay for glow plug warm up. You can choose from a selection of “pre-cranking” delay times. NOTE: This feature is OFF by default and must be programmed before use. Once a delay time is selected, the Remote start unit will always wait the programmed time before cranking EVEN IF the glow plug warms up first. -
Page 14: Options Programming
OPTIONS PROGRAMMING NOTES: (1) Options #2, #4 and #5 DO NOT APPLY TO THE RS-810 MODEL (NO KEYLESS ENTRY) (2) RS-810 Tap the Brake Pedal to select/toggle the option values. * = Default Value Option Option Description Option Values Button #1 Button #2 LOCK UNLOCK... - Page 15 OPTIONS PROGRAMMING 2. RS-830 ONLY Auto Lock/Unlock: This option controls whether the doors will automatically lock/unlock on your vehicle when driving or with turning the Ignition ON/OFF. If the Auto Lock feature is turned on, and the system is in Tach mode, then the doors will lock as the engine RPM’s increase (driving).
-
Page 16: Transmitter Programming
RS-830/810 TRANSMITTER CODE LEARNING Transmitter Code Learning: Notes: Remote Transmitters come pre-programmed from the Factory. When re-learning remotes or adding remotes, ALL your system’s remote codes must be learned at time of programming!! These systems allow storage of up to 4 different remote codes in memory. -
Page 17: Vehicle Operation
2-VEHICLE OPERATION The RS-830/810 systems can be used for 2 vehicle operation. A single remote can control a second vehicle with an identical system installed. There are some exceptions. See “Multi-Vehicle Notes” section below. VEHICLE #2 Pressing the lower side button on your remote Press lower side button transmitter switches your remote to car #2 mode for 3-seconds. -
Page 18: Troubleshooting "Before You Call" Section
TROUBLESHOOTING: “BEFORE YOU CALL” SECTION UNIT WILL NOT ATTEMPT A START (KEYLESS ENTRY FUNCTIONS NORMALLY): The unit is in Valet mode. Turn IGN ON, press and hold valet/programming button for 5-6 seconds then turn key off. Unit is now out of valet mode and should remote start. If optional LED is installed, then it will be on solid when in Valet. SYSTEM IS UNSUCCESSFUL AT REMOTE START DURING EXTREME COLD CONDITIONS: Please be aware that during sub-freezing conditions your remote starter may take more that one attempt to start, or it may not successfully start the vehicle after 3 attempts. -
Page 19: Jumper Pin, Antenna, & System Diagrams
JUMPER PIN & ANTENNA DIAGRAMS Jumper pins are used to configure the operation of the on board multi-function output PINK/WHITE wire and the Parking Light WHITE wire. See the diagram below for Jumper Pin configurations. ACC 2 CONTROL MODULE IGN 2 (DEFAULT) STARTER 2 (-) NEGATIVE PARKING LIGHT (500 mA) +12V (10A) PARKING LIGHT (DEFAULT) - Page 20 NOTE: USE EXTERNAL RELAYS FOR HIGH-CURRENT FUEL A/C - HEAT TRANSMISSION ENGINE PUMP (GREATER THAN 30A) IGNITION CIRCUITS. CONTROL IGN #2 or START #2 JUMPER STARTER ACC #2 or (Only if necessary) SELECT STR #2 STARTER +/- PARKING BROWN LIGHT GRAY VEHICLE JUMPER...
