  • Page 2 Panel PC User Manual Release Date Revision Jan. 2013 V1.0 ® 2013 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan Aplex Technology, Inc. 15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: aplex@aplex.com.tw...

  • Page 3: Warning

    Disclaimer This information in this document is subject to change without notice. In no event shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or consequential, arising from either the use or misuse of information in this document or in any related materials.

  • Page 4: Packing List

    Always disconnect power when the system is not in use. ◆ Disconnect power when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. APC-3918P User Manual...

  • Page 5: Table Of Contents

    3.8 Advanced Chipset Settings..............50 3.9 Exit Options..................57 Chapter 4 Installation of Drivers 4.1 Intel Chipset Driver.…………………………...…………………………60 4.2 Intel(R) VGA Chipset Driver……………..……………………………..63 4.3 Intel(R) Network Adapter………………………………………………….66 4.4 Realtek Audio Driver Installation………………….………….…………69 4.5 Microsoft .NET Framework 3.5 Service Installation……………………72 APC-3918P User Manual...
  • Page 6 5.1 Introduction to Controller Board..…………………………..……………74 5.2 Windows 2000/XP USB Driver Installation………………….………..….74 Figures Figure 1.1: APC-3218 Dimensions……………………………………..…..8 Figure 1.2: Front View of APC-3918P………………………………………...12 Figure 1.6: Rear View of APC-3918P………………………………………..12 Figure 1.7: Panel mounting of APC-3918P…………………………………..13 Figure 1.8: VESA mounting of APC-3918P…………………………………..13 Figure 2.1: Mainboard Dimensions…………………………………..……..14...

  • Page 7: Specifications

    2 x 2W Speaker for option OS Support Windows XP Professional, XP Embedded, Windows Embedded Standard 7, Windows 7 Pro for Embedded Display Size 19” 1280x1024 Maximum Colors 16.2M Viewing Angle H:170 / V:160 (Degree) Luminance (cd/m²) Backlight Lifetime 50,000 Hours APC-3918P User Manual...
  • Page 8 Aluminum front bezel and steel chassis IP Rating Front Panel IP65 Mounting Panel / VESA 100x100 Mount Dimensions 484x400x83 (WxHxD) Net Weight 11.8kgs -10~50℃ Operating Temperature -20~60℃ Storage Temperature 10%~90%@ 40℃, non-condensing Relative Humidity Certificate CE / FCC Class A APC-3918P User Manual...

  • Page 9: Dimensions

    1.2 Dimensions Figure 1.1: Dimensions of APC-3918P APC-3918P User Manual...

  • Page 10: Installation Of Hdd

    HDD bracket. Step 2 There is 1 screw to deal with when enclosing or removing the HDD Tray. Step 3 Gently remove the screw and draw the HDD bracket out as shown in the picture. APC-3918P User Manual...
  • Page 11 Step 4 Tighten four screws as shown in the picture. F Screw M3*5L 120° Step 5 Push into the HDD bracket as shown in the picture Step 5 That‟s how it should look after it has been installed. APC-3918P User Manual...

  • Page 12: Installation Of Pci Add-On

    After sliding the add on into the PCI expansion slot, get the one screw as circled tightened to finish the connection. Step 3 To finish the job, just fasten the 2 screws as shown in the picture. APC-3918P User Manual...

  • Page 13: Brief Description

    1.5 Brief Description of APC-3918P APC-3918P is Intel Socket P Core 2 Duo Intel GM45+ ICH9M-E Steel Panel PC, which comes with a 19-inch (luminance of 350 cd/m²) TFT LCD. It is powered by an Intel Socket P Core 2 Duo Processor, up to Intel P8600 2.4GHz processor.

  • Page 14: Panel Mounting

    1.6 Panel Mounting of APC-3918P APC-3918P panel PC is designed to be panel-mounted as shown in Figure 1.7. Just carefully place the unit through the hole and tighten the given 10 screws from the rear to secure the mounting. Figure 1.4: Panel mounting of APC-3918P Figure 1.5: VESA mounting of APC-3918P...

  • Page 15: Chapter 2 Hardware

    Chapter 2 Hardware 2.1 Mainboard Figure 2.1: Mainboard Dimensions APC-3918P User Manual...

  • Page 16: Installations

    PC104+ port (capable of adjusting IO voltage) richer extension functions. The product is widely used in various sectors of industrial control. 2.2.1 Jumpers Setting and Connectors Figure 2.2: Jumpers and Connectors Location_ Board Top APC-3918P User Manual...

  • Page 17: Figure 2.3: Jumpers And Connectors Location_ Board Bottom

    (2.0mm Pitch 1X2 Pin Header),ATX Power and Auto Power on jumper setting. Mode Open ATX Power Close Auto Power on (Default) 2. RTC/SRTC: (2.0mm Pitch 1X2 Pin Header)CMOS clear jumper, CMOS clear operation will permanently reset old BIOS settings to factory defaults. RTC/SRTC CMOS APC-3918P User Manual...
  • Page 18 Signal Pin# Name Pin1 VBAT PIN2 Ground 4. DCIN: (5.08mm Pitch 1x3 Pin Connector),DC9V ~ DC32V System power input connector。 Power Pin# Input DC+9V~32 Pin1 Pin2 Ground Pin3 Ground Location Location Location (5.4.6.) Power Mode (5.4.4.) (5.4.5.) APC-3918P User Manual...
  • Page 19 (2.0mm Pitch 1X3 box Pin Header), connect PSON and 5VSB and Ground signal,support ATX Power model. Reserved. Pin# Signal Name Pin1 ATX PSON PIN2 ATX Ground PIN3 ATX 5VSB 7. CPU1: (Socket P), installing the CPU Socket. APC-3918P User Manual...
  • Page 20 (CRT 2.0mm Pitch 2X5 Pin Header), Video Graphic Array Port, Provide 2x5Pin cable to VGA Port, they can not work at the same time for CRT and VGA1. Signal Name Pin# Pin# Signal Name CRT_RED Ground CRT_GREEN Ground CRT_BLUE VGA_EN CRT_H_SYN CRT_DDCDAT APC-3918P User Manual...
  • Page 21 Intel GM45 chipset, the interface features dual channel 18/24-bit output. Signal Name Pin# Pin# Signal Name VDD5 VDD5 Ground Ground VDD33 VDD33 LB_D0_N LA_D0_N LB_D0_P LA_D0_P Ground Ground LB_D1_N LA_D1_N LA_D1_P LA_D1_P Ground Ground LB_D2_N LA_D2_N APC-3918P User Manual...
  • Page 22 (Type DB9),Rear serial port, standard DB9 Male serial port is provided to make a direct connection to serial devices. COM1 port is controlled by pins No.1~6 of JCOM1,select output Signal RI or 5V or 12v, For details, please refer to description of JCOM1. Pin# Signal Name APC-3918P User Manual...
  • Page 23 RTS (Request To Send) CTS (Clear To Send) RI (Ring Indicator) 18. COM5: (2.0mm Pitch 2X5 Pin Header),COM5 Port, standard RS232 ports are provided. They can be used directly via COM cable connection. Signal Pin# Pin# Signal Name Name Ground APC-3918P User Manual...
  • Page 24 Rear LAN port, Two standard 10/100/1000M RJ-45 Ethernet ports (RJ45 are provided. Used Intel 82574L chipset, LINK LED (green) and ACTIVE LED (yellow) respectively located at the left-hand and right-hand side of the Ethernet port indicate the activity and transmission state of LAN. APC-3918P User Manual...
  • Page 25 Onboard buzzer. 26. JP_104P: (2.0mm Pitch 1X3 Pin Header) PC104+ port voltage selection jumper, select voltage The default for this jumper is “all open”,meaning the for PCI-104 Plus devices. user must select the voltage to be used. APC-3918P User Manual...
  • Page 26 PCI-PME for PCI 31. MIO1: (1.25mm Pitch 2x20 Connector),For expand output connector, It provides two RS232 ports or one RS485 port, three USB ports, one power led, one power button, via a dedicated cable connected to TB-522 MIO1. APC-3918P User Manual...
  • Page 27 Pin# Pin# Signal Name Function H_LED+ HDD_LED PWR-LED P_LED+ H_LED- Ground Ground P_LED- RESET- Ground MIO_PSON- PSON+ RESET RESET Ground PSON- BUZZER+ BUZZER- BUZZER- BUZZER+ GPIO_IN_1 GPIO_OUT_1 GPIO_I GPIO_IN_2 GPIO_OUT_2 GPIO_OU GPIO_IN_3 GPIO_OUT_3 GPIO_IN_4 GPIO_OUT_4 Ground 5V_S5 APC-3918P User Manual...
  • Page 28 Pin19-24: PS2 KB/MS, PS/2 keyboard and mouse port, the port can be connected to PS/2 keyboard and mouse via a dedicated cable for direct used. Pin25-40: USB0/USB1/USB2/USB3, Front USB connector, it provides 4 USB ports via a dedicated USB cable, speed up to 480Mb/s. APC-3918P User Manual...
  • Page 29 Output current of the connector must not be above 1A. 35. SATA1/SATA2/SATA3/SATA4: SATA Connectors, Four SATA connectors are provided, with transfer speed (SATA 7P), up to 3.0Gb/s. SATA1/SATA2/SATA3 drives supporting RAID 0 or RAID 1 function. ASB-M801ET/EB: APC-3918P User Manual...
  • Page 30 MPCIE1 SCREW HOLES, H5 for H6 for card (30mmx50.95mm) assemble. 39. LED1: LED STATUS. Green LED for Motherboard Standby Power Good status, Yellow LED for HDD status. 40. TB-522: ASB-M801 I/O Card, via a dedicated cable connected to ASB-M801 MIO1. APC-3918P User Manual...
  • Page 31 PWR LED: status. POWER LED COM3: (Type DB9),I/O serial port, it provides selectable RS422/RS485 serial signal output. RS422 Type (option) RS485 Type (option) Signal Name Pin# Pin# Signal Name 422_RX+ 422_RX- 422_TX- 485- 422_TX+ 485+ Ground Ground APC-3918P User Manual...
  • Page 32 Card socket), it is located at TB-522 and serves as an insert interface for Type I and Type II Compact Flash card. The operating voltage of CF card can be set as 3.3V or 5V. The default setting of the product is 3.3V. APC-3918P User Manual...
  • Page 33 41. TB-520P1: TB-520P1 connect to ASB-M801T/ET PC104+ connector, PC104+ is located at the top, It provides one PCI slot. APC-3918P User Manual...

  • Page 34: Chapter 3 Bios Setup

    Press F11 key to enter Boot Menu during POST, as shown by the following figure. Please select boot device： Network: IBA GE Slot 0200 v1353 Network: IBA GE Slot 0300 v1353 ↑and ↓ to move selection ENTER to select Boot device ESC to boot using defaults APC-3918P User Manual...

  • Page 35: Bios Setup Utility

    Select a field Build Date : 05/13/11 Use[+] or [-] to : M801V001 configure system Time. Processor Genuine Intel(R) CPU @ 2.00GHz Speed :2000MHz ← Select Screen ↑↓ Select Item System Memory Charge Field Size :1981MB Tab Select Field APC-3918P User Manual...

  • Page 36: Advanced Settings

    ► CPU Configuration ► IDE Configuration ► Super IO Configuration ► Hardware Health Configuration ► ACPI Configuration ► AHCI Configuration ► MPS Configuration ► PCI Express Configuration ► Smbios Configuration ← Select Screen ► USB Configuration APC-3918P User Manual...
  • Page 37 Execute-Disable Bit Capability [Enabled] +- Charge Field Intel(R) C-SATAE tech [Disabled] F1 General Help F10 Save and Exit ESC Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. Hardware Prefetcher: [Enabled] [Disabled] Adjacent Cache Line Prefetch: APC-3918P User Manual...
  • Page 38 +- Charge Field ► Third IDE Master : [Not F1 General Help Detected] F10 Save and Exit ► Fourth IDE Master : [Hard ESC Exit Disk] Hard Disk Write Protect [Disabled] IDE Detect Time Out (Sec) [35] APC-3918P User Manual...
  • Page 39 [IDE] [RAID] [AHCI] SATA#2 Configuration: [Enhanced] [Disabled] Hard Disk Write Protect: [Disabled] [Enabled] IDE Detect Time Out : [35] [10] [15] [20] [25] [30] ATA(PI) 80Pin Cable Detection: [Host & Device] [Host] [Device] 3.4.3 Super IO Configuration APC-3918P User Manual...
  • Page 40 COM3 Options: [RS485 ] [RS422] [RS422] for RS422 Mode [RS485] for RS485 Mode 3.4.4 Hardware Health Configuration BIOS SETUP UTILITY Advanced Hardware Health Configuration System Temperature :33℃/91℉ 55℃/131℉ 60℃/140℉ CPU Temperature :30℃/86℉ 65℃/149℉ CPUFAN Speed :4800 RPM APC-3918P User Manual...
  • Page 41 Show you the current CPU temperature. CPUFAN Speed: Show you the current CPU Fan operating speed. Maximum CPU Temperature: [60℃/140℉] 55℃/131℉ 65℃/149℉ 70℃/158℉ Minimum PWM Duty for CPU Fan: [60%] [50%] [70%] [80%] 3.4.5 ACPI Configuration ACPI Setting: [Advanced ACPI Configuration] APC-3918P User Manual...
  • Page 42 High Performance Event Timer: [Disabled] [Enabled] 3.4.6 AHCI Configuration BIOS SETUP UTILITY Advanced AHCI Setting Enables For supporting AHCI BIOS Support [Enabled] AHCI CD/DVD Boot Time out [35] ► AHCI Port0 [Not Detected] ► AHCI Port1 [Not Detected] APC-3918P User Manual...
  • Page 43 +- Charge Field F1 General Help F10 Save and Exit ECS Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. MPS Revision: [1.1] [1.4] 3.4.8 PCI Express Configuration BIOS SETUP UTILITY Advanced PCI Express Configuration Enables/Disables APC-3918P User Manual...
  • Page 44 Smbios Smi Support [Enabled] Support for PnP Func 50h-54h ← Select Screen ↑↓ Select Item Charge Field General Help F10 Save and Exit ESC Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. Smbios Smi Support: [Enabled] [Disabled] APC-3918P User Manual...

  • Page 45: Advanced Pci/Pnp Settings

    Personal Computer Interconnect, is a computer bus that allows I/O device to operate nearly as fast as CPU in its own way. Some technical terms will be mentioned here. We recommend that non-professional users not make changes from factory default settings. APC-3918P User Manual...
  • Page 46 F10 Save and Exit IRQ5 ESC Exit [Available] IRQ7 [Available] IRQ9 [Available] IRQ10 [Available] IRQ11 [Available] V02.61 © Copyright 1985-2006 American Mega trends , Inc. Clear NVRAM: [No] [Yes] Plug & Play OS: [No] [Yes] PCI Latency Timer: [64] APC-3918P User Manual...
  • Page 47 Available: Specified IRQ is available to be used by PCI/PnP devices. Reserved: Specified IRQ is reserved for use by legacy ISA devices. DMA Channel 0/1/3/5/6/7: [Available] [Reserved] Available: Specified DMA is available to be used by PCI/PnP devices. APC-3918P User Manual...

  • Page 48: Boot Settings

    V02.61 © Copyright 1985-2006 American Mega trends , Inc. Boot Setting Configuration： Configure Settings during System Boot. Quick Boot: [Enabled] [Disabled] Allows BIOS to skip certain tests while booting .This will decrease the time needed to boot the system. APC-3918P User Manual...
  • Page 49 [Disabled] Interrupt 19 Capture: Enabled: Allows option ROMs to trap interrupt 19. [Disabled] [Enabled] Boot Device Priority: Specifies the Boot Device Priority sequence. Hard Disk Devices : Specifies the Boot Device Priority sequence from available Hard Drives. APC-3918P User Manual...

  • Page 50: Security Settings

    Always: Check password while invoking setup a well as on each boot. Boot Sector Virus Protection: [Disabled] [Enabled] Enabled / Disabled Boot Sector Virus Protection. Type the password with up to 6 characters and then press Enter key. This will APC-3918P User Manual...

  • Page 51: Advanced Chipset Settings

    ► North Bridge Configuration ► South Bridge Configuration ← Select Screen ↑↓ Select Item Enter Go to sub screen General Help F10 Save and Exit ESC Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. APC-3918P User Manual...
  • Page 52 ► Video Function Configuration ESC Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. Memory Remap Feature: [Enabled] [Disabled] Memory Hole: [Disabled] [15MB-16MB] Initate Graphic Adapter: Select which graphics controller to use as the primary boot device. APC-3918P User Manual...
  • Page 53 +- Charge option Backlight Control Level [Level 8] F1 General Help Backlight Control Mode [DC] F10 Save and Exit Backlight Image Adaptation ESC Exit [VBIOS-Default] V02.61 © Copyright 1985-2006 American Mega trends , Inc. DVMT Mode Select: APC-3918P User Manual...
  • Page 54 [1024x768 24bit 2ch] [1280x1024 24bit 2ch] [1440x900 24bit 2ch] [1600x900 24bit 2ch] [1680x1050 24bit 2ch] [1920x1080 24bit 2ch] Backlight Control Support [VBIOS-Default] [Both BLC & BIA Disabled] [BLC Enabled] Backlight Control Control: [Level8] [Level0] [Level1] [Level2] [Level3] [Level4] APC-3918P User Manual...
  • Page 55 Ports] 2 USB Ports USB2.0 Controller [Enabled] 4 USB Ports 6 USB Ports Keep USB Power at S5 [Enabled] 8 USB Ports Wireless Controller [Enabled] 10 USB Ports HAD Controller [Enabled] 12 USB Ports SMBUS Controller [Enabled] APC-3918P User Manual...
  • Page 56 [2 USB Ports] [4 USB Ports] [6 USB Ports] [8 USB Ports] [10 USB Ports] USB 2.0 Controller: [Enabled] Keep USB Power at S5: [Enabled] [Disabled] Wireless Controller [Enabled] [Disabled] HDA Controller: [Enabled] [Disabled] SMBUS Controller: [Enabled] [Disabled] APC-3918P User Manual...
  • Page 57 PCIE Port 0: [Auto] [Enabled] [Disabled] PCIE Port 1: [Auto] [Enabled] [Disabled] PCIE Port 2: [Auto] [Enabled] [Disabled] PCIE Port 3: [Auto] [Enabled] [Disabled] PCIE Port 4: [Auto] [Enabled] [Disabled] PCIE High priority Port: [Disabled] [Port 0] [Port1] [Port2] APC-3918P User Manual...

  • Page 58: Exit Options

    ← Select Screen ↑↓ Select Item Enter Go to sub screen General Help F10 Save and Exit ESC Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. Save Changes and Exit: Save configuration changes and exit setup? APC-3918P User Manual...
  • Page 59 F7 key can be used for this operation) [OK] [Cancel] Load Optimal Defaults: Load Optimal Defaults? F9 key can be used for this operation) [OK] [Cancel] Load FailSafe Defaults: Load FailSafe Defaults? F9 key can be used for this operation) [OK] [Cancel] APC-3918P User Manual...

  • Page 60: Chapter 4 Installation Of Drivers

    Codec Driver, Microsoft .NET Framework 3.5 Service, Touch Panel Driver. Installation instructions are given below. Important Note: After installing your Windows operating system (Windows XP), you must install first the Intel Chipset Software Installation Utility before proceeding with the installation of drivers. APC-3918P User Manual...

  • Page 61: Intel Chipset Driver

    4.1 Intel Chipset Driver To install the Intel chipset driver, please follow the steps below. Step 1. Access driver list as shown below. Select Intel GM45/ICH9M Chipset Driver from the list Step 2. Click Next to set up program. APC-3918P User Manual...
  • Page 62 Step 3. Click Yes to accept all of the terms of the license agreement. Step 4. Click Next to continue. APC-3918P User Manual...
  • Page 63 Step 5. Click Next. Step 6. Select Yes, I want to restart this computer now. to restart the computer. Click Finish, then remove any installation media from the drives. APC-3918P User Manual...

  • Page 64: Intel(R) Vga Chipset Driver

    4.2 Intel(R) VGA Chipset Driver To install the VGA driver, follow the steps below to proceed with the installation. Step 1. Select Intel(R) VGA Chipset Driver. Step 2. Click Next to continue the set up program. APC-3918P User Manual...
  • Page 65 Step 3. Click Yes to continue. Step 4. Click Next. Step 5. Read the license agreement. Click Yes to accept all of the terms of the license agreement. APC-3918P User Manual...
  • Page 66 Step 6. Readme File Information screen appears. Click Next to continue. Step 7. Click Next. APC-3918P User Manual...

  • Page 67: Intel(R) Network Adapter

    Step 8. Select Yes, I want to restart this computer now. to restart the computer. Click Finish to complete installation. 4.3 Intel(R) Network Adapter To install Intel (R) Network Adapter device driver, please follow the steps below. Step 1. Select Intel(R) Network Adapter from the list APC-3918P User Manual...
  • Page 68 Step 2. Click Next to continue the installation. Step 3. Select I accept the terms in the license agreement. APC-3918P User Manual...
  • Page 69 Step 4. Tick Drivers, Intel(R) PROSet for Windows* Device Manager, Advanced Network Services. Click Next to continue the installation. Step 5. Click Install to begin installation. APC-3918P User Manual...

  • Page 70: Realtek Audio Driver Installation

    Step 6. Click Finish to complete the installation. 4.4 Realtek Audio Driver Installation To install the Realtek ALC662 Audio Codec Driver, please follow the steps below. Step 1. Access the driver list as shown below. Select Realtek ALC662 Audio Codec Driver. APC-3918P User Manual...
  • Page 71 Step 2. Click Next. Step 3. The installation files are extracted.. APC-3918P User Manual...
  • Page 72 Step 4. Select Yes, I want to restart my computer now. and click Finish. The system reboots. APC-3918P User Manual...

  • Page 73: Microsoft .Net Framework 3.5 Service Installation

    To install the Microsoft .NET Framework 3.5 Service, please follow the steps below. Step 1. Access the driver list as shown below. Select Microsoft .NET Framework 3.5 Service. Step 2. Select I have read and ACCEPT the terms of the License Agreement. Click Install to continue. APC-3918P User Manual...
  • Page 74 Step 3. The installation can be monitored in the progress bar shown in below. Step 4. When the driver installation is completed, click Exit. APC-3918P User Manual...

  • Page 75: Figure 5.1 Birdeye"S View Of Control Board

    Windows 7 support. Figure 5.1: Bird’s Eye View of Control Board 5.2 Windows 2000/XP/2003/Vista Universal Driver Installation Before installing the Windows 2000/XP driver software, you must have the Windows 2000/XP system installed and running on your computer. APC-3918P User Manual...
  • Page 76 When the system first detects the controller board, a screen appears that shows “Unknown Device”. Do not use this hardware wizard. Press Cancel. Insert the product CD install setup.exe. the screen below would appear. Click Touch Panel Driver Step 1. Click Next to install eGalax Touch on your computer. APC-3918P User Manual...
  • Page 77 Step 2. Tick Install RS232 interface driver. Step 3. Select None, then click Next. APC-3918P User Manual...
  • Page 78 Step 4. There is a pop-up. Click OK. Step 5. Tick Support Multi-Monitor System and click Next. Step 6. Click Browse to create new folder. Click Next to continue settings. APC-3918P User Manual...
  • Page 79 Step 7. Under eGalaxTouch folder, select Accessories. Click Next to continue. Step 8. Tick Create a eGalaxTouch Utility shortcut on desktop. Click Next. APC-3918P User Manual...
  • Page 80 Step 9. eGalaxTouch is configuring your new software installation. Step 10. Click Yes to do 4 point calibration. APC-3918P User Manual...
  • Page 81 5.2.2 Software Functions General In this window, you can see there is USB Controller. Click OK to continue. Monitor Mapping to adjust the touch panel to search for the device APC-3918P User Manual...
  • Page 82 Beep Beep On Touch Beep On Release Beep From System Beep Beep From Sound Card Linearization Style 9 points 25 points Double Click Time Shorter Longer Double Click Area Smaller Bigger Normal mode Simulate the mouse mode APC-3918P User Manual...
  • Page 83 Option Function Enable Constant Touch Enable Auto Right Click Enable Touch Enable Cursor Stabilization Constant Touch Area Auto Right Click Time APC-3918P User Manual...
  • Page 84 Do 4 points alignment to match display. Clear and Calibrate Clear linearization parameter and do 4 points alignment. Linearization Do 9 points linearization for better touchscreen linearity. Draw Test Do draw test to verify the touch accuracy. APC-3918P User Manual...
  • Page 85 Display In this window, it shows the mode of display. Enable Multiple Monitors. Map to main display if system has only one display monitor Full Screen Lower Screen Left Screen Upper Screen Right Screen APC-3918P User Manual...
  • Page 86 Other Other mode of display. Quarter1~4 and Customized area. Active Area Drag active area to enable Active Area Function. APC-3918P User Manual...
  • Page 87 Hardware Saturn Hardware Configuration APC-3918P User Manual...
  • Page 88 About To display information about eGalaxTouch and its version. APC-3918P User Manual...
