Rack Mount Kit: RMK-1600
The RMK-1600 is a complete rack mount kit that has been developed for the Crestron
LC-1600L/W-DB & DW and CT-1600L/W-DB & DW touchpanel models. Use the supplied
hardware to assemble the rack mount kit to the touchpanel.
Supplied Hardware
The RMK-1600 consists of two items with differing quantities. These items along with the
touchpanel produce an assembly that can be attached to a rack. Rack-mounting hardware is
not supplied.
Assembly View
Assembly of the RMK-1600 to the touchpanel is illustrated below. Crestron recommends the
use of a #2 Phillips head screwdriver to secure the four supplied screws with a torque of
11 in-lbs (1.243 N*m). The only difference between the two sides of the rack plate is that a
barcode appears on one side. The barcode side should be hidden from view once installed in
a rack. Use caution when handling the touchpanel as not to damage or scratch the view
screen. The RMK-1600 is designed to occupy four rack spaces, 7.0 inches (17.78 cm).
TOUCHPANEL
Further Inquiries
If after reviewing this sheet for the RMK-1600, you cannot locate specific information or have
questions, please take advantage of Crestron's award winning customer service team by
calling:
For local support from exclusive Crestron factory-trained personnel call:
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
Tel: 888.CRESTRON
Fax: 201.767.7576
ITEM
Rack Mount Plate
Screw, Pan Phil
COVER
In the US and Canada, call Crestron's corporate headquarters at
1-888-CRESTRON [1-888-273-7876] or 1-201-767-3400.
In Europe, call Crestron International at +32-15-50-99-50.
In Asia, call Crestron Asia at +852-2341-2016.
In Latin America, call Crestron Latin America at +525-260-4336.
In Australia, call Soundcorp at +613-9488-1555.
In New Zealand, call Amber Technologies at +649-410-8382.
PART NUMBER
QUANTITY
17501
#6-32 x 0.25" LG
Specifications subject to change without notice.
1
4
SCREWS
RACK PLATE
Installation Guide – DOC. 5851A
Rack Mount Kit: RMK-1600
www.crestron.com
12.00
