Crestron RMK-1500 Install Manual

Rack Mount Kit: RMK-1500
The RMK-1500 is a complete rack mount kit that has been developed for LC-1500W
and CT-1600W touchpanel models. Use the supplied hardware to attach the supplied
19 inch (48.26 cm) rack panel to the touchpanel.

Supplied Hardware

19" (48.26 cm) Rack Panel

Assembly View

Rack-Mount View

Once the rack panel is secured to the touchpanel with the mounting hardware, the assembly (shown
below) is ready to be mounted to the rack. Rack-mounting hardware is not supplied.
ITEM
Screw, Flat Phil
Nut, Hex
Washer, Lock
PART NUMBER QUANTITY
02218
#6-32 x 0.5" LG
#6-32
#6
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
Tel: 888.CRESTRON / 201.767.3400
Fax: 201.767.7576 / BBS: 201.767.5506
www.crestron.com
1
4
4
4
Specifications subject
to change without notice.
Doc. 5754
03.99
