Crestron RMK-TPS3000L Installation Manual

Rack Mount Kit: RMK-TPS3000L
The RMK-TPS3000L is a complete rack mount kit that has been developed for the Crestron
TPS-3000L series of wall-mounted touchpanels. Use the supplied hardware to attach the
touchpanel to the rack mount kit.

Supplied Hardware

The RMK-TPS3000L consists of a mounting plate and screws to secure the touchpanel to the
plate. These items along with the touchpanel produce an assembly that can be attached to a
rack. Rack-mounting hardware is not supplied.
Rack Mounting Plate, 6 RU High
Screw, 6-32, 1/4"L, Pan, Phil, Blk

Assembly View

Assembly of the RMK-TPS3000L to the
touchpanel is illustrated to the right. Before
installation, remove the plastic touchpanel
faceplate if it is attached. Use a #2 Phillips
head screwdriver to secure the touchpanel to
the rack mounting plate with the four supplied
screws (do not use the screws supplied with
the touchpanel). Torque should not exceed
11 in-lbs (1.243 N*m). Use caution when
handling the touchpanel as not to damage or
scratch the view screen. The RMK-TPS3000L
is designed to occupy six rack spaces, 10.47
inches (26.59 cm) high. After the touchpanel
is secured to the rack plate, reinstall the
touchpanel faceplate and attach the plate to
the rack.
