- Page 1 KGS-1064-BP Industrial Managed 10-Port Gigabit Ethernet Switches with 2 Dual-speed SFP Slots and 8 PoE PSE Ports (IEEE 802.3bt PoE) Firmware Rev1.0 up User’s Manual DOC.210223A...
- Page 2 (such as translation or transformation) without permission from KTI Networks Inc. KTI Networks Inc. reserves the right to revise this documentation and to make changes in content from time to time without obligation on the part of KTI Networks Inc. to provide notification of such revision or change.
- Page 3 The information contained in this document is subject to change without prior notice. © Copyright All Rights Reserved. TRADEMARKS Ethernet is a registered trademark of Xerox Corp. FCC NOTICE This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including the interference that may cause undesired operation.
-
Page 4: Table Of Contents
Table of Contents 0B1. Introduction ..............................5 1.1 Features ..........................6 1.2 Product Panels ........................7 1.3 LED Indicators ........................8 1.4 Specifications ........................8 1B2. Installation ..............................11 10B2.1 Unpacking ........................11 2.2 Safety Cautions ........................11 12B2.3 DIN-Rail Mounting ......................12 13B2.4 Panel Mounting ...................... -
Page 5: 0B1. Introduction
1. Introduction The KGS-1064-BP is a 10-port industrial managed Gigabit Ethernet switch which is featured with the following communication ports: ⚫ Eight 10/100/1000Mbps Gigabit copper ports with PoE function ⚫ Two dual-speed SFP slots for 100Base-FX 1000Base-X ⚫ One RS-232 console port... -
Page 6: Features
1.1 Features ⚫ Eight 10/100/1000Mbps RJ-45 and two dual-speed SFP slots ⚫ All copper ports support auto-negotiation and auto-MDI/MDI-X detection. ⚫ All copper ports are equipped with 802.3bt-compliant PoE PSE function ⚫ Two SFP slots support dual speed for 100BASE-FX and 1000BASE-X SFP transceivers. ⚫... -
Page 7: Product Panels
1.2 Product Panels The following figure illustrates the front panel and rear panel of the switch: Front panel Top panel 154B... -
Page 8: Led Indicators
1.3 LED Indicators Function Power status Mgt. Management status Port 1~ 8 SPEED LEDs Speed & PoE status Port 1~ 8 LINK LEDs Link & activity status SFP 9, 10 LEDs Speed & link & activity status of SFP port 1.4 Specifications 10/100/1000 Copper Ports (Port 1 ~ Port 8) Compliance... - Page 9 Maximum packet length 9.6K bytes IP Multicast groups 8192 supported Flow control IEEE 802.3x pause frame base for full duplex operation Back pressure for half duplex operation Power over Ethernet PSE Function PSE Ports Port 1 ~ Port 8 Standard IEEE 802.3af, IEEE 802.3at, and IEEE 802.3bt PD classes support PSE port output vs.
- Page 10 NC contacts: normal – shored, alarm – open NO contacts: normal – open, alarm – shored Alarm events Power failure, Specific port link fault (software configured), OPA Mechanical 856BU Dimension 140 x 106 x 60 mm (HxDxW) Housing Enclosed metal with no fan Mounting Din-rail mounting, Panel mounting (optional) Environmental...
-
Page 11: 1B2. Installation
2. Installation 2.1 Unpacking The product package contains: ⚫ The switch unit ⚫ QR code label ⚫ One console cable 2.2 Safety Cautions To reduce the risk of bodily injury, electrical shock, fire and damage to the product, observe the following precautions: Do not service any product except as explained in your system documentation. -
Page 12: 12B2.3 Din-Rail Mounting
2.3 DIN-Rail Mounting In the product package, a DIN-rail bracket is provided for mounting the switch in a industrial DIN-rail 171B enclosure. The steps to mount the switch onto a DIN rail are: 172B Install the mounting bracket onto the switch unit as shown below: 1287B Attach bracket to the lower edge of the DIN rail and push the unit upward a little bit until the bracket can 1288B... - Page 13 Dimensions: -13-...
-
Page 14: 13B2.4 Panel Mounting
2.4 Panel Mounting The switches are provided with an optional panel mounting bracket. The bracket supports mounting the switch 173B on a plane surface securely. The mounting steps are: Install the mounting bracket on the switch unit. 1290B Screw the bracket on the switch unit. 1291B Screw the switch unit on a panel. - Page 15 Dimensions: -15-...
-
Page 16: 14B2.5 Applying Power
2.5 Applying Power Power pins of the terminal block connector Vdc Positive ( ) input terminal − Vdc Negative ( ) input terminal Vdc Input specifications Working voltage range Applications Power output at PSE port +12V ~ +60VDC General +45V ~ +57VDC PoE, PoE+ +51V, 36W max. -
Page 17: Alarm Relay Output
2.6 Alarm Relay Output Alarm relay output is provided for reporting failure events to a remote alarm relay monitoring system. The replay output is provided with three contacts (support two logic types) in the terminal block connector next Vdc interfaces. Alarm Relay output pins and logic: Alarm relay output, NO (Normal Open) contacts Open: Normal, Shorted: Alarm... -
Page 18: Reset Button
2.7 Reset Button The reset button is used to perform a reset to the switch. It is not used in normal cases and can be used for diagnostic purpose. If any network hanging problem is suspected, it is useful to push the button to reset the switch without turning off the power. -
Page 19: Making Utp Connections
2.8 Making UTP Connections The 10/100/1000 RJ-45 copper ports support the following connection types and distances: Network Cables 10BASE-T: 2-pair UTP Cat. 3, 4, 5 , EIA/TIA-568B 100-ohm 100BASE-TX: 2-pair UTP Cat. 5, EIA/TIA-568B 100-ohm 1000BASE-T: 4-pair UTP Cat. 5 or higher (Cat.5e is recommended), EIA/TIA-568B 100-ohm Link distance: Up to 100 meters for all above Auto MDI/MDI-X Function... -
Page 20: Making Fiber Connection
2.9 Making Fiber Connection The dual-speed SFP slots, Port 9 and Port 10 must be installed with an SFP fiber transceiver for making fiber connection. The switch may come with one or two SFP transceivers pre-installed when it is shipped. Types of the SFP Fiber transceivers supported: 1000Mbps based 1000BASE-X SFP transceivers 100Mbps based 100BASE-FX SFP transceivers... - Page 21 before making cable connection. The following figure illustrates a connection example between two fiber ports: Make sure the Rx-to-Tx connection rule is followed on the both ends of the fiber cable. Network Cables Multimode (MMF) - 50/125m, 62.5/125m Single mode (SMF) - 9/125m Port Speed Configuration There are three options for configuring port speed via software for SFP Port 9 and Port 10.
-
Page 22: Making Poe Pse Connections
2.10 Making PoE PSE Connections This section describes how to make a connection between a PSE port and a PoE Powered D device (PD). All copper ports are equipped with PoE PSE function. The ports are enabled to deliver power together with network signal to a connected powered device via Cat.5 cable. - Page 23 4. The power is cut off immediately from powering condition when a disconnection occurs. 5. The power is cut off immediately from powering condition when overload occurs. 6. The power is cut off immediately from powering condition when over-current occurs. 7.
-
Page 24: Led Indication
2.11 LED Indication Function Color State Interpretation Power Green The power is supplied to the switch. status The power is not supplied to the switch. Management status Green The switch is in initialization and diagnostics. Yellow BLINK Initialization completed with diagnostic error or system Green Initialization completed with no error... -
Page 25: Making Console Connection
2.12 Making Console Connection The connector designed for the console port is RJ-45. Pin Assignments RS-232 signals IN/OUT 1, 2, 7, 8 4, 5 Baud Rate information Baud rate - 115200 Data bits - 8 Parity - None Stop bit - 1 Flow control –... -
Page 26: Managing The Switch
3. Managing the Switch The switch provides the following methods to configure and monitor the switch as follows: ⚫ Making out of band telnet CLI management via the console port ⚫ Making in-band management via telnet CLI over TCP/IP network ⚫... -
Page 27: Configuring Ip Address Via Web Interface
Parameters: <ipv6_addr> : IPv6 address is in 128-bit records represented as eight fields of up to four hexadecimal digits with a colon separates each field (:). <ipv6_prefix> : IPv6 subnet mask <ipv6_router> : IPv6 router [Password] setting command is also in Security/Switch/Users command group. Security Switch Users Configuration Security Switch Users Add <user_name>... - Page 28 No password is required. Click to login into the switch. Web Page after a Successful Login Select [Configuration] -> [System] -> [IP] to configure IP address Configuration Description -28-...
-
Page 29: Reference Manuals For Web, Console, Telnet Management
DHCP Client Enable the DHCP client by checking this box. IP Address Provide the IP address of this switch unit. IP Mask Provide the IP mask of this switch unit. IP Router Provide the IP address of the default router for this switch unit. Provide the managed VLAN ID. -
Page 30: Configuration For Snmp Management
3.5 Configuration for SNMP Management The switch supports SNMP v1, SNMP v2c, and SNMP v3 management. Make sure the related settings are well-configured for the switch before you start the SNMP management from an SNMP manager. Using Telnet Interface The following are available commands in telnet SNMP command group to configure SNMP-related settings: >SNMP Configuration >SNMP Mode [enable|disable] >SNMP Version [1|2c|3]... -
Page 31: Snmp Mibs
>SNMP View Delete <index> >SNMP View Lookup [<index>] >SNMP Access Add <group_name> <security_model> <security_level> [<read_view_name>] [<write_view_name>] >SNMP Access Delete <index> >SNMP Access Lookup [<index>] Using Web Interface Select [Configuration] -> [Security] -> [SNMP]: The commands supports configuration for: Basic system configuration for SNMP v1 and SNMP v2c Basic system configuration for SNMP v1 trap, SNMP v2c trap and SNMP v3 trap Communities that permit to access to SNMPv3 agent USM (User-based Security Model) user table for SNMPv3... -
Page 32: Snmp Traps
- RFC 4188 - Bridge MIB - RFC 4668 - RADIUS Authentication Client MIB - RFC 5519 - Multicast Group Membership Discovery (MGMD) MIB - IEEE 802.1 MSTP MIB - IEEE 802.1AB LLDP MIB - IEEE 802.1X Port Access Entity (PAE) MIB - TIA 1057 LLDP Media Endpoint Discovery (MED) MIB - IEEE 802.1-Q-BRIDGE MIB - Private SFPDDM MIB (Read DDM status of the SFP ports) -
Page 33: Redundant Ring Applications
4. Redundant Ring Applications 4.1 Auto Multi-Ring Technology Auto Multi-Ring Technology was developed especially for switches connected in ring topology which needs redundant support when any failure occurs in ring. For large network, more than one ring connections are very common. -
Page 34: Redundant Ring Applications With Industrial Standard Rstp Protocol
The following figure shows one switch is configured to support three redundant rings and one RSTP ring at the same time. 4.2 Redundant Ring Applications with industrial standard RSTP protocol It also can be done to support a ring connection using industrial standard RSTP function and establish a backup path.
