Koden GTD-120 Quick Start Manual
Chart plotter
Hide thumbs
Also See for GTD-120:
- Operation manual (248 pages) ,
- Quick start manual (3 pages) ,
- Quick reference (2 pages)
Table of Contents
Related Manuals for Koden GTD-120
Summary of Contents for Koden GTD-120
- Page 1 Chart Plotter GTD-120 Features User-friendly Operation C-Map chart Ready 10.4 inch High brightness LCD Various marks and greater numbers of ship’s track Bird view function AIS display (Option) SD Card capable, save user data such as marks, tracks and settings...
- Page 2 SPECIFICATIONS EQUIPMENT LIST 構成品目 Standard Display unit Display unit GTD-120 Equipment Display size and type 10.4 inch color TFT LCD DC power cable Map mode Mercator projection Spare parts Presentation modes North-up, East-up, South-up, West-up, Operation manual Course-up (Waypoint),Head-up Quick Reference Display Resolution 480 × 640 (VGA) Option GPS Sensor, GPS Compass, GPS anttena support holder 0.01 to 1,000 NM (or 0.02 to 2,000 km) Zooming range AIS Interface, Various connection cables, Power Rectifier Effective map Below the latitude 80 degree creation area Plotting Time DIMENTIONS AND WEIGHT 1, 2, 5, 10, 20, 30, 60, 120, 300, 600 sec 外観寸法図・重量 interval 0.01, 0.02, 0.05, 0.1, 0.2, 0.5, 1.0, 2.0, 5.0, 10.0 NM / km Distance Number of plots 2,000 / 4,000 / 5,000 / 7,000 / 10,000 / 20,000 points (Upper limit points can be selectable from 6types) ＋ ...
