New GPS Navigator
KGP-915
Koden Electronics Co., Ltd.
December 2016
December 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KGP-915 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Koden KGP-915

  • Page 1 New GPS Navigator KGP-915 Koden Electronics Co., Ltd. December 2016 December 2016...
  • Page 2 Update to the new model KGP-913MkII KGP-915 December 2016...
  • Page 3 Specifications 1/3 Specifications Contents KGP-915 KGP-913MkII Model Display Unit:KGP-915.MU Display Unit:KGP-913.MU Antenna:GA-09 Antenna:GA-08 Display type 4.3 inch TFT color LCD 128 x 64 dot STN LCD Receiving 1575.42MHz±1MHz 1575.42MHz±1MHz frequency 1602MHz±4MHz Receiving channel Parallel 72 channel Parallel 18 channel Sensitivity...
  • Page 4 Specifications 2/3 Specifications Contents KGP-915 KGP-913MkII Presentation Nav Data, Steering Mode Highway, Plotter → Satellite Monitor, Setting Memory Waypoint :10,000 points Waypoint :400 point Route :100 x 50 points Route :20 points Trail :3,000 points Trail :2,000 points Alarm Positioning, Anchor, Arrival, →...
  • Page 5 Specifications 3/3 Specifications Contents KGP-915 KGP-913MkII Sentence AAM, APB, BOD, BWC, DCN ← GGA, GLC, GLL, GSA, GSV ← MSS, RMB, RMC, RTE,VTG ← WDC, WPL, XTE, ZDA ← Power supply 10.8V to 31.2VDC ← Power 4.5W or less ←...
  • Page 6 External appearance (Front side of display unit) Unit (mm) December 2016...
  • Page 7 External appearance (Side surface of display unit) Unit (mm) December 2016...
  • Page 8 External appearance (Rear side of display unit) Unit (mm) Weight:0.74kg December 2016...
  • Page 9 External appearance (GA-09) Weight:2.2kg December 2016...
  • Page 10 Description on Display Unit Keys Display Unit Mounting bracket Installation Knobs December 2016...
  • Page 11 Description on keys Cursor Shift Menu (Up/Down/ Emergency Right/Left) Mode Numeric Keys Clear Enter Power ON/OFF Brightness (8 levels) December 2016...
  • Page 12 Screen There are total 6 screens as below; Press to switch the screen sequentially. Nav 1 Screen Nav 2 Screen Nav 3 Screen Steering Screen Highway Screen Plotter Screen December 2016...
  • Page 13 Nav 1 Screen Waypoint Date / Time DOP/DGPS Route Number Alarm Number Current Position Speed Course December 2016...
  • Page 14 Nav 2 Screen Waypoint Number Speed Distance to waypoint Course Bearing to waypoint December 2016...
  • Page 15 Nav 3 Screen Distance to waypoint Bearing to waypoint Course Elapsed Time Speed Time to waypoint Latitude / Longitude at waypoint December 2016...
  • Page 16 Steering Screen Distance to Waypoint Course waypoint Scale Current Position December 2016...
  • Page 17 Highway Screen Waypoint Own Ship Position Scale Current Position Deviation December 2016...
  • Page 18 Plotter Screen Waypoint Own Ship Position Route Scale Current Position December 2016...
  • Page 19 Menu KGP-915 has 10 menus. Move the cursor by shifting and press Or, input the menu number directly to move to the desired menu. December 2016...
  • Page 20 Menu 1: Waypoint Move the cursor by shifting and press Or, input the waypoint number directly and press Remarks Waypoint number December 2016...
  • Page 21 Menu 2: Route Move the cursor by shifting and press Or, input the number directly to move to the desired menu. December 2016...
  • Page 22 Menu 2-1: Select the route Move the cursor by shifting and press Or, input the route number directly and press December 2016...
  • Page 23 Menu 2-1: Select the route Make the direction of route by shifting Select the first waypoint and press to start the route navigation. December 2016...
  • Page 24 Menu: GNSS Move the cursor by shifting and press Or, input the number directly to move to the desired menu. GPS+GLONASS GLONASS December 2016...
  • Page 25 Menu 3-1: GNSS Monitor Satellite Number Elevation angle Azimuth December 2016...
  • Page 26 Menu 3-1: GNSS Monitor December 2016...
  • Page 27 Menu 4: DGNSS Move the cursor by shifting and press Or, input the number directly to move to the desired menu. Auto / SBAS / Beacon / Off December 2016...
  • Page 28 Menu 5: Compensation Move the cursor by shifting and press Or, input the number directly to move to the desired menu. December 2016...
  • Page 29 Menu 6: Alarm Move the cursor by shifting and press Or, input the number directly to move to the desired menu. December 2016...
  • Page 30 Menu 7: Calculation Move the cursor by shifting and press Or, input the number directly to move to the desired menu. December 2016...
  • Page 31 Menu 8: Initialization Move the cursor by shifting and press Or, input the number directly to move to the desired menu. December 2016...
  • Page 32 Menu 9: Interface Move the cursor by shifting and press Or, input the number directly to move to the desired DATA1 menu. 4800 / 9600 / 19200 / 38400 DATA2 Follow the system / GP fixed December 2016...
  • Page 33 Menu 9-5: Sentence Edit Edit the sentences so that the bar graph would be less than 100%. December 2016...
  • Page 34 Menu 10: Plotter Move the cursor by shifting and press Or, input the number directly to move to the desired menu. December 2016...
  • Page 35 Connections KBG-3 GA-09 memory Plotter Auto Pilot Radar DATA2 DATA1 December 2016...
  • Page 36 Thank you for your attention! December 2016...
