chapter 5
Additional Operational Information
Front Panel
Generator/Parameter
Controls
This section details the parameter features
available from the multi-function SET, UP,
DOWN and RUN/STOP, CLEAR switches.
(Referred to as Set, Up, Down and Run).
Generator start, stop and related functions
of the Set, Up, Down and Run switches are
explained in "Generating and Regenerat-
ing Time Code" on page 44.
Parameters
The USD 7-segment LEDs are not able to
show all upper and lower case characters
properly, and in some cases use numerals
to represent letters (such as "5" to represent
"S" or "s"). The following table identifies
each of these abbreviations.
To select USD front panel parameters:
Press Set.
1
Use the Up and Down switches to scroll
2
through available parameters, described
below.
Detailed instructions for the multi-func-
tion Generator/Parameter switches can be
found in the section "Using the Front Panel
Generator/Parameter Switches" on
page 29.
USD LED display of abbreviated parameter names
USD LED Parameter
SE7 6En Set Generator Start Time
dI6 rEF Digital Reference
SPL FrEC Sample Freq (Rate)
VI7C InS VITC Insertion
rdr LInE (VITC) Reader Line
6En LInE (VITC) Generate Line
burn EnA Window Burn On/Off
FrEE LEn Freewheel Duration
L7C 6AIn LTC Output gain
PICH HLd Pitch Hold On/Off
bIPH PPF Bi-Phase Pulse-per-frame
bIPH SI6 Bi-Phase Signal Configuration
VIdEO SY Video System/Format
(NTSC/PAL)
IdLE 7C Idle MTC On/Off
