General
Vibration Resistance
Shock
Operating Temperature
Storage Temperature
Relative Humidity
Power Requirements
Agency Compliance
5 mm displacement, 10 to 55 Hz, each axis
5 G max
32 to 131 degrees F (0 to 55 degrees C)
-40 to 176 degrees F (-40 to 80 degrees C)
0 to 95%, non-condensing
Voltage:
Frequency:
Wattage:
Connector:
Meets FCC Part 15 Class A limits, CE EN 55022A, CE EN
60950, CE EN 55082:1, UL 1419 and CSA 22.2
85 to 264 VAC
47 to 63 Hz autoswitching
9.5 W typical, 30 W maximum
3-pin, AC and ground (IEC
950:320;3.2.4)
Appendix B: Technical Specs 75
