Rear Panel Connectors
Connector
Video (Main) Out
Video (Ref) In
Video (Ref) Out
AES Clock In
AES Clock Out
Word Clock In
Word Clock Out
Specifications
Level:
Source Impedance:
Format:
Level:
Termination:
Level:
Termination:
Description:
Level:
Connector:
Level:
Connector:
Level:
Connector:
Level:
1V p-p
75 ohms
NTSC or PAL composite video
1V p-p
100K ohms
1V p-p
100K ohms
Passive loop-thru of Video Ref in
5 V p-p at 110 ohms (pin 2 hot)
3-pin XLR female per IEC 268-12
5 V p-p at 110 ohms (pin 2 hot)
3-pin XLR male per IEC 268-12
0 to .5 V (low), 2.0 to 6.0 V (high)
BNC Female
TTL (3.3 V typical)
