5. Operation Controls and Functions

5.1 Transmitter Panel

Number Name
1 USB(TO PC)
2 POWER LED
DC 12V
3
4 CAT port
1 2
USB port, connect to the USB port of a PC through a
USB-B male head to USB-A male head wire.
Power LED indicator. The green LED will illuminate when
transmitter is connected with power supply.
Plug DC 12V/1A power supply into the unit and connect
the adapter to an AC outlet.
The CAT port is connected to receiver's CAT port via a
CAT5e/6 cable.
DC 12V
3
Function Description
3 / 5
CAT
4
