10) Press the Tabs of the Lens together. Then slide the Lens off
the Fascia. (Store the Lens in a safe place, for future use.)
11) Secure the Fascia to the Cover using the five
previously removed Screws.
12) Lower the Cover onto the printer. Reinstall and
tighten the three Cover Screws. Tighten both
Hinge Screws. Reinstall the Door and lower
the Cover. Plug the power cord into the AC
Receptacle. Align the scanner; see "Alignment"
section, below.
Lens
Fascia
Cover
Cover
Screws
5
Fascia
Tabs
Screws
Hinge
Screws
Door
