4) Remove the Plug from the Center Plate
Aperture.
5) Secure the mini-din connector of the
Cable Assembly (Item 5) to the Center
Plate Aperture using two Screws (Item
4) and two Nuts (Item 3).
6) After routing the Cable Assembly away from movable
parts, attach its 8-pin connector to J13 of the Backplane
CCA.
Center Plate
Aperture
Center Plate
Screws
3
Plug
Cable
Aperture
Assembly
Backplane
CCA
J13
Cable
Assembly
Nuts
