1) Turn OFF the Power Switch and unplug the
power cord from the AC Receptacle.
2) Press down on the Catch, then pull forward to remove
the Door.
3) Raise the Cover. Loosen both Hinge
Screws. Remove the three Cover Screws,
and then lift the Cover off the printer.
Remove any media and ribbon from the
printer.
Catch
Door
Cover
Screws
2
Power Switch
AC Receptacle
Cover
Hinge
Screws
