7) Secure the Scanner and Mounting
Assembly (Item 1) to the Center Plate
using three Screws (Item 2).
8) Connect the Scanner Cable to the Center
Plate Connector.
9) Remove the five Screws that secure the Fascia to the
Cover.
Center Plate
Screws
Center Plate
Connector
Fascia
4
Scanner and
Mounting Assembly
Scanner
Cable
Screws
Cover
