- Page 1 ULB34 Rear Window Phantom PLIT533 REV. - 9/15/15...
- Page 2 Mounting Instructions 1. The typical mounting area for this light is along the top moulding inside the rear hatch. 2. Alternately the light can be mounted to the trim above the window, on the rear hatch itself.
- Page 3 (Mounting CONT’D) 2. Attach the mounting brackets to the back of the light. Leave the screws loose to allow for bracket adjustment. 3. Hold the light up to the location where it is to be mounted. We recommend aligning the corner of the bend in the bracket with the rear edge of the moulding above the rear window.
- Page 4 Reverse polarity may cause serious damage to the lightbar and/or vehicle. Contact the automotive dealer if there are any doubts about the polarity of your vehicle. The ULB34 is powered through the 4-wire harness that comes pre installed on the light. Connect the four wires as follows:...
- Page 5 Pattern Programming PLEASE NOTE : The green wire is only used for programming purposes during installation. 1. Connect the black wire to Ground. 2. Activate the light by applying power (+12VDC) to the red wire. 3. Briefly touch and release the green wire to ground to scroll through the patterns listed below.
- Page 6 These lights use state-of-the-art Light Emitting Diode (LED) technology. This light is comprised of ultra-bright LEDs that are operated in a multiplexed mode to efficiently produce light output with lifetimes up to 100,000 hours. Under normal circumstances, you will not need to replace any LEDs in this light. If any of the LED's in your light do fail, please contact Star Headlight for arrangements to have them repaired.
