205 RACKS (CMA-44H)
205 RACKS (CMA-44H)
4. On a 3-phase machine the water pump motors are also 3-phase and, depending on
which terminal each phase is connected to, the motor can rotate in either direction.
Check the direction of rotation by removing the dust cap on the back of the motor.
The motors must turn clockwise looking at the shaft from the back of each motor.
To change the direction of rotation, switch any two power lead wires at the motor.
5. The machine must be running to set the pressure regulator. While the machine is in
the FINAL RINSE CYCLE, adjust the pressure regulator to 20 PSI. See section
3.1.3 Rinse Pressure Regulator
MODEL CMA-44 Installation & Operation Manual Rev. 2 .15 10/18/07
P/N 13505.10
P/N 13505.12
OLD Models
B
A
C
Figure 2.3.3b
for detailed instructions.
Getting Started
242 RACKS (CMA-44L)
167 RACKS (M-1)
242 RACKS (CMA-44L)
Page
7
