Quadratec 97109.2002 Manual

J3 hood mount light bar mounting brackets for 1997-2006 wrangler tj

Download this manual

J3 Hood Mount Light

Bar Mounting Brackets

For 1997-2006 Wrangler TJ Vehicles:

Passenger

PARTS LIST:

Hood Light Mounting Brackets - QTY 2

T40 Torx Head Bolts & Washers - QTY 6

*Hardware included with J3 lightbar.

Driver

REQUIRED TOOLS:

Safety Glasses

5mm Hex/Allen Key

T40 Torx Bit/Socket

Ratchet Driver & Extension

READ ALL SAFETY MESSAGES AND UNDERSTAND ALL

INSTRUCTIONS BEFORE ATTEMPTING TO INSTALL THIS

PRODUCT. ALWAYS WEAR SAFETY GLASSES DURING INSTALL.

The Trusted Source

97109.2002

*Hardware included with lightbar.

Need help?

Do you have a question about the 97109.2002 and is the answer not in the manual?

Page 1 J3 Hood Mount Light Bar Mounting Brackets For 1997-2006 Wrangler TJ Vehicles: 97109.2002 *Hardware included with lightbar. Passenger Driver PARTS LIST: REQUIRED TOOLS: Hood Light Mounting Brackets - QTY 2 Safety Glasses T40 Torx Head Bolts & Washers - QTY 6 5mm Hex/Allen Key *Hardware included with J3 lightbar.
Page 2 Bracket Installation: Put on Safety Glasses. With the hood Torx bit and ratchet. (it may be neces- securely latched in place, locate the sary to score the paint around the bolts three T40 Torx bolts on both hood using and razor blade to prevent paint hinges and remove them using a T40 chipping.) With the Factory bolts removed install...
Page 3 Lightbar Installation: After loosely installing, carefully check While supporting the light bar parallel to make sure the light bar fits snugly to the hood install the 6mm socket between the two brackets. You may headed screw, lock washer and flat need to make some minor adjustments.
Page 4 Quadratec to obtain a RGA number only to Quadratec branded accessories first sold (610-701-3336). All labor, removal, shipping in the United States, Quadratec warrants to the and installation costs are customer’s initial retail purchaser only that your responsibility.
