Quadratec
Brute
®
Strength Side Steps
Installation Manual for 4 Door '18- Current Wrangler JL Vehicles
#
12057.0271
TO REDUCE RISK OF SERIOUS INJURY OR PROPERTY DAMAGE:
READ ALL SAFETY MESSAGES AND UNDERSTAND ALL INSTRUC-
TIONS AND PROCEDURE NOTI ES BEFORE ATTEMPTING TO
INSTALL OR USE THIS PRODUCT. FOLLOW ALL INSTRUCTIONS
AND WARNINGS WITH PRODUCT & VEHICLE OWNERS MANUAL.
THIS PRODUCT IS INTENDED TO REDUCE RISK OF OFF-ROAD
BODY PANEL DAMAGE AND ASSIST IN ENTRY/EXIT FROM
VEHICLE. YOUR SIDE STEP IS NOT INTENDED TO INCREASE
OCCUPANT PROTECTION OR REDUCE VEHICLE DAMAGE IN
EVENT OF ACCIDENT.
PROPERLY TORQUE AND RECHECK FASTENERS AND SECURITY
OF STEP TREAD AFTER 250 MILES AND FREQUENTLY THERE-
AFTER. INSPECT AND DO NOT USE AS A STEP IF DAMAGED.
DO NOT USE SIDE STEPS AS A WINCH/SELF-RECOVERY
ATTACHMENT POINT.
CHECK STATE AND LOCAL HIGHWAY SAFETY LAWS REGARDING
PERMITTED ON-ROAD EQUIPMENT.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Quadratec Brute Strength 12057.0271
Summary of Contents for Quadratec Brute Strength 12057.0271
- Page 1 Quadratec Brute ® Strength Side Steps Installation Manual for 4 Door ’18- Current Wrangler JL Vehicles 12057.0271 TO REDUCE RISK OF SERIOUS INJURY OR PROPERTY DAMAGE: READ ALL SAFETY MESSAGES AND UNDERSTAND ALL INSTRUC- TIONS AND PROCEDURE NOTI ES BEFORE ATTEMPTING TO INSTALL OR USE THIS PRODUCT.
- Page 2 Careful attention is required to this instruction or operation but does ® generally not relate to personal injury. Damage to your Quadratec product or other property may result if you don’t follow instructions. Before You Begin Installation:...
- Page 3 Installation Hardware: PARTS LIST: Required Tools: Driver (Left) Side Step QTY 1 Safety Glasses Passenger (Right) Side Step QTY 1 13mm Socket with Ratchet Driver 13mm Wrench A) M8 x 25 mm Hex Bolts QTY 18 B) 8mm Flat Washers QTY 30 C) 8mm Lock Washers QTY 6...
-
Page 4: Installation Is Complete
Brute Strength Side Steps Installation: FIG 3 FIG 4 Install the 8mm hex head bolts through Do not fully tighten at this time. the pinch weld and the mounting Repeat on the other side bracket holes. brackets with washers on both sides (FIG 4) and secure with a 8mm nylock nut using a 13mm hex wrench and a 13mm... - Page 5 Product Care and Maintenance: Your Side Steps have been designed For any required touch ups, we recom- and manufactured to provide years of mend using a textured black spray paint use. However, like any product, general sprayed on a piece of cardboard and maintenance is required to keep them cotton swab to gently fill in these chips.
- Page 6 Quadratec to obtain a RGA number only to Quadratec branded accessories first sold (610-701-3336). All labor, removal, shipping in the United States, Quadratec warrants to the and installation costs are customer’s initial retail purchaser only that your responsibility.
