Quadratec
for Jeep
REQUIRED TOOLS:
SAFETY GLASSES
TORX T15 SCREW DRIVER
KIT CONTENTS:
INTERIOR DOOR PULL
HANDLES (PAIR)
Interior Door Pull Handles for 97-06
Wrangler TJ and LJ Vehicles
Thank you for purchasing our Interior
Door Pull Handles. Installation is easy
and takes about 20 minutes. Please
note: Door has been removed for illustra-
tion purposes. Removal is not required.
®
Door Pull Handles
®
Wrangler TJ Vehicles
Installation and Instruction Sheet
14117.0008
#
READ ALL SAFETY MESSAGES AND ALWAYS WEAR
SAFETY GLASSES WHEN WORKING WITH TOOLS.
Torx T15
Screw Driver
The Trusted Source
Step One: Remove 5 Torx Head Screws
Put on safety glasses. Remove the 5 Torx
head T15 sheet metal screws that hold
the door panel and the interior door pull
handle. Retain all fasteners for later use.
®
Figure 1
Advertisement
Table of Contents
Related Manuals for Quadratec 14117.0008
Summary of Contents for Quadratec 14117.0008
- Page 1 ® Quadratec Door Pull Handles ® for Jeep Wrangler TJ Vehicles Installation and Instruction Sheet 14117.0008 READ ALL SAFETY MESSAGES AND ALWAYS WEAR SAFETY GLASSES WHEN WORKING WITH TOOLS. REQUIRED TOOLS: SAFETY GLASSES TORX T15 SCREW DRIVER KIT CONTENTS: INTERIOR DOOR PULL...
- Page 2 Step Two: Separate Interior Panel Step Three: Install Door Pull Gently separate the interior door panel Install the Quadratec Door Pull while from the door but do NOT completely lining up the grommet holes with the remove the plastic door panel. This sep- clip-on nuts on the door.
- Page 3 Figure 5 Grommet Grommet Note: The “ghosted” images shown above and left show grommet holes lined up with the factory clip-on nuts on the door. With one door complete, repeat the process for opposite side of Clip-on nut Clip-on nut vehicle from which you started.
- Page 4 Quadratec to obtain a RGA number only to Quadratec branded accessories first sold (610-701-3336). All labor, removal, shipping in the United States, Quadratec warrants to the and installation costs are customer’s initial retail purchaser only that your responsibility.
