QuadraTop
This Complete Soft Top kit is designed to fit on your Jeep® Wrangler when the
original soft top or hard top has been completely removed. Before beginning
NOTICE
your installation of this product, you will need to remove your existing soft top
fabric, hardware or Hard top.
Loss of vehicle control involves risk of death or serious injury, particularly to
parts of your body not restrained within vehicle. This product is intended for
weather protection only and should not be relied upon to contain occupants
in the event of an accident or to protect from either ground contact or falling
objects. To reduce risk of accident or injury:
•
ALWAYS WEAR SEATBELTS
WARNING
•
Always keep head, arms & body parts within vehicle.
•
Fully secure or stow the soft top before driving according to instructions.
Never try to latch or fold soft top while driving. Do not use if damaged or
worn.
•
Read and follow all instructions & warnings accompanying this product, in
your vehicle owner's manual and Off Road Driving Supplement.
RISK OF EYE INJURY. Safety glasses should be worn at all times while install-
CAUTION
ing or maintaining this product.
HARDWARE PART LIST:
BOW ASSEMBLIES (L & R)
WINDSHIELD CHANNEL
SIDE BELT RAIL (L & R)
CORNER BELT RAIL (L & R)
TAILGATE BRACKETS W/SCREWA (L & R)
BOW CONECTOR
UPPER DOOR WINDSHIELD INSERT (L &R) QTY 2
TAILGATE BAR
5/16" TORX SCREWS
5/16" TAPPING PLATES
5/16" FLAT WASHERS
#8X1/2" PAN SELF SCREWS
#8X1/4" TAP MOD SCREWS
(Note: There maybe an exra hardware in package)
Complete Soft Top
®
for 87-95
Jeep
Wrangler YJ
®
Item
11100.50XX, 11100.7026
#
SOFT PART LIST:
QTY 2
FABRIC TOP
QTY 1
QUARTER WINDOWS RIGHT
QTY 2
QUARTER WINDOWS LEFT
QTY 2
REAR WINDOW
QTY 2
UPPER DOOR SKIN RIGHT
QTY 2
UPPER DOOR SKIN LEFT
DOOR FRAME RIGHT
QTY 1
DOOR FRAME LEFT
QTY 12
QTY12
REQUIRED TOOLS:
QTY 12
SAFETY GLASSES
QTY 10
PHILLIPS HEAD SCREWDRIVER
QTY 11
#40 TORX SOCKET AND DRI-
VER PLIERS
1/8" DRILL BIT (OPTIONAL)
3/16" DRILL BIT (OPTIONAL)
SHOE HORN OR LARGE SPOON
RAZON KNIFE
PHILLIPS SCREWDRIVER
SOFT BEACH SIZE TOWEL
QTY1
QTY1
QTY1
QTY1
QTY1
QTY1
QTY1
QTY1
DRILL
Advertisement
Related Manuals for Quadratec QuadraTop 11100.50 Series
Summary of Contents for Quadratec QuadraTop 11100.50 Series
- Page 1 QuadraTop Complete Soft Top ® for 87-95 Jeep Wrangler YJ ® Item 11100.50XX, 11100.7026 This Complete Soft Top kit is designed to fit on your Jeep® Wrangler when the original soft top or hard top has been completely removed. Before beginning NOTICE your installation of this product, you will need to remove your existing soft top fabric, hardware or Hard top.
- Page 2 CAUTION you don’t follow instructions. Careful attention is required to this instruction or operation but does general- ly not relate to personal injury. Damage to your Quadratec® product or other NOTICE property may result if you don’t follow instructions. Before you begin Installation:...
- Page 3 Step 2B: Install Upper Door Windshield Inserts IF you are installing soft top hardware for the first time, Locate the upper driver’s side upper door wind- shield insert and position it over the windshield flange lining up the horizontal reinforcement with the top of the flange.
- Page 4 Step 5b: Tailgate Bracket Installation Bracket should line up with FIG 13 inside edge of tailgate. IF you are soft top hardware for the first time, Locate the passenger and Drivers side Tailgate Brackets, (4) #10 - 24x ½” Phillips machine screws included. Take the passenger sidetailgate bracket and line it up with the edge of theinside of the tailgate as shown in Fig 13.
- Page 5 Unfold the flat vertical and horizontal Step 8a: Attach Bows to Windshield Inserts stamping and slide the front bow (with FIG 18 foam) forward raising the horizontal over door surround towards the front wind- shield. The front and rear bows should lock into the notch in the belt rail.
- Page 6 Step 11: Install Top Fabric into the Windshield Channel FIG 26 FIG 27 Insert the front plastic windshield retainer strip sewn along the front of the top into the Windshield Channel front slot. Do not catch any fabric in the channel. While installing, make sure the top is centered side to side in the channel so that there is an equal dis- tance from the center of the windshield.
- Page 7 Release the spreader bars. Line up and Step 16: Install Side Curtains attach the top and side zippers on the side curtains approximately 2-3 inches. FIG 35 FIG 36 Note that the side zipper may not line up Top Zipper with the corner fabric unless you slide the corner fabric around in the belt rail towards the front of the vehicle.
- Page 8 Step 21: Securing theRear Tailgate Retainer FIG 44 FIG 45 With the rear curtain attached, “roll” the rear tailgate bar into the two rear tailgate retainers. Once engaged into the retainers, slip the rear curtain plastic retainers into the bottom of the tailgate retainer channel. zippers closed.
- Page 9 (do not use “polished” out using the window polish listed the brush on the window glass!). You on page 15 (Available at Quadratec.com). can also use special soft top clean- ers Water/Fabric: In the event of seeping available on our website and shown on page 15.
- Page 10 Quadratec, Inc. 1028 der shall, upon Quadratec inspection and Saunders Lane, West Chester, PA 19380. at Quadratec’s option, be either repair or replacement of product or parts (new or This Limited Warranty is the only warranty refurbished) covered under this Limited Warranty.
