Tire Relocation Bracket
Installation Manual: for 2018-Current Wrangler JL
TO REDUCE RISK OF SERIOUS INJURY OR PROPERTY DAMAGE:
READ ALL SAFETY MESSAGES AND UNDERSTAND ALL INSTRUCTIONS AND
PROCEDURE NOTICES BEFORE ATTEMPTING TO INSTALL OR USE THIS
PRODUCT. FOLLOW ALL INSTRUCTIONS AND WARNINGS WITH PRODUCT &
VEHICLE OWNERS MANUAL.
PLEASE CONSULT YOUR VEHICLE'S OWNER MANUAL FOR THE MAXIMUM
SPARE TIRE WEIGHT YOUR VEHICLE IS DESIGNED TO SUPPORT. IF YOU
EXCEED THE MAXIMUM WEIGHT, THEN ADDITIONAL SUPPORT BELOW THE
SPARE TIRE IS STRONGLY RECOMMENDED.
RISK OF EYE INJURY! SAFETY GLASSES MUST BE WORN AT ALL TIMES
WHILE INSTALLING OR MAINTAINING THIS PRODUCT. TORQUE AND
RECHECK FASTENERS AFTER 250 MILES AND FREQUENTLY THEREAFTER.
INSPECT BUMPER AND HITCH BEFORE USE.
Tailgate Spare
®
#12226.3011
