Allow the Installer Code to Access the User Menu - Option 12

LED Keypad
Hold down the [*] key until the beep, enter [MASTER CODE] [*] [1] [2] [*] [*] [#]
Enter the User Program Mode as per steps 1 to 4 in section User Program Mode.
1.
Press the [1] [2] keys followed by the [*] key to select programmable option 12.
2.
The READY and ARM LEDs flash simultaneously.
3.
The READY and AWAY LEDs flash simultaneously, and the ARM LED will be on.
4.
The option to allow the installer code to access the user menu will be shown.
5.
Press [*] key to toggle the option on or off.
6.
LCD Keypad
Enter the User Program Mode as per steps 1 - 4 of section User Program Mode.
1.
The LCD display reads 'Option Menu', 'Add User Code'.
2.
To select menu option 12 – 'Installer Access properties', press the [1] [2] keys or alternatively use the
3.
[PANIC] or [MED] keys to scroll through the list of programmable options until you reach 'Global
Options'
Press the [*] key.
4.
The LCD display reads 'I code access OFF'.
5.
Press [*] key to toggle the options value. OFF = Installer has access, ON = Installer has no access.
6.
Press the [#] key twice to exit User Program Mode.
7.
User Outputs – Option 13 (Advanced)
LED Keypad
Hold down the [*] key until the beep, then enter [MASTER CODE] [*] [1] [3] [*] [USER CODE] [*] [OUTPUT No]
Enter the User Program Mode as per steps 1 to 4 in section User Program Mode.
1.
Press the [1] [3] keys followed by the [*] key to select programmable option 13.
2.
The READY and ARM LEDs flash simultaneously.
3.
Enter the [USER CODE] followed by the [*] key.
4.
The READY and AWAY LEDs flash simultaneously, and the ARM LED will be on.
5.
Enter the [OUTPUT No] followed by the [*] key. (Refer to Table 8).
6.
The POWER and READY LEDs flash simultaneously, and the ARM and AWAY LEDs are on.
7.
Enter the [OUTPUT ACTION] followed by the [*] key. (Refer to Table 7).
8.
The READY and ARM LEDs flash simultaneously.
9.
Repeat steps 4 - 9 until all the user outputs you want have been entered.
10.
Press the [#] key to exit the current option.
11.
Press the [OPTION NUMBER] followed by the [*] key for the next option, or the [#] key again to exit user
12.
programming.
LCD Keypad
[*] [MASTER CODE] [*] [1] [3] [*] [USER CODE] [*] [OUTPUT No] [*] [OUTPUT ACTION] [*] [#]
Enter the User Program Mode as per steps 1 - 4 of section User Program Mode.
1.
The LCD display reads 'Option Menu', 'Add User Code'.
2.
To select menu option 13 –'User Outputs', press the [1] [3] keys or alternatively use the [PANIC] or
3.
[MED] keys to scroll through the list of programmable options until you reach the option.
Press the [*] key.
4.
The LCD display reads 'User Code + *'.
5.
Enter the [USER CODE] followed by the [*] key.
6.
The LCD display reads 'Output No. + *'.
7.
Enter the [OUTPUT No] followed by the [*] key.
8.
The LCD display reads 'Action + *'.
9.
Enter the [OUTPUT ACTION] followed by the [*] key.
10.
Repeat steps 6 - 10 until all the user outputs have been entered.
11.
Press the [#] key to exit the User Program Mode.
12.
NOTE: (Please see page 24)
[*] [MASTER CODE] [*] [1] [2] [*] [*] [#]
[OUTPUT ACTION] [*] [#]
700-398-01J X-Series User Manual Issued for version 2.8x
[*]
23
