Inhep Digital Security IDS816 Installer's Manual

Wiring and keypad programming
Hide thumbs
Table of Contents

Advertisement

Quick Links

IDS
IDS816
IDS816
Installer Guide to Wiring and
Keypad Programming
MANUAL NO. 700-283-02 B ISSUED NOVEMBER 2004 VERSION 2.00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IDS816 and is the answer not in the manual?

Questions and answers

Related Manuals for Inhep Digital Security IDS816

Summary of Contents for Inhep Digital Security IDS816

  • Page 1 IDS816 IDS816 Installer Guide to Wiring and Keypad Programming MANUAL NO. 700-283-02 B ISSUED NOVEMBER 2004 VERSION 2.00...

  • Page 2: Table Of Contents

    Communicator Options ........... 36 17.6.7 Partition Setup ............45 17.6.8 User Options ............53 17.6.9 Programmable Output Options ....... 56 17.6.10 Keypad Options ............57 17.6.11 Installer Options ............59 IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 3 Value for Day of the Week ........35 Table 11: Standard Contact I.D Reporting Codes ....39 Table 12: Standard Contact I.D Reporting Codes ....53 Tabe 13: Location Number - User Codes ......54 IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 4 For correct operation the IDS816 must be used in conjunction with the specified transformer/battery combination and appropriate peripheral sensors and signalling devices.
  • Page 5 The panel can be programmed to arm /disarm at a pre-determined time. Fax defeat / answering machine override. Dual reporting provides for duplicated reporting to two independent central base stations. Dynamic battery self test. Low battery cutout circuit. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 6 IDS816 INSTALLER MANUAL Please refer to Figure 1: Connection Diagram and familiarise yourself with the following sections. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 7 ! Panic zones always register panic and tamper conditions. ! The colour codes for the 12K and 4K7 resistors are as per in Figure 4. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...

  • Page 8: Box Tamper Input

    The box tamper input does not require an end-of- line resistor. Use a normally closed contact only. When installing an expander module refer to the document supplied with the module. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...

  • Page 9: Programmable Outputs

    Current sink is via a 1000Ω resistor to negative. The output circuitry is shown in Figure 5. A momentary key-switch or non-latching remote control receiver may be connected to any zone to allow remote arm/disarm and remote panic capability. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...

  • Page 10: Key-Switch Or Remote Control Unit

    Factory default values will be restored to all locations and all attached keypads I.D’s will be defaulted IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 11 If defaulted the download code will revert back to 9999. A value of [1] [0] programmed into this location will prevent the download code from being defaulted when performing a hardware reset. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 12 For example: assume the following zone indicators are illuminated: Zone 1, Zone 3 and Zone 4. The value equals the sum of the values displayed by zone LEDs [1], [3],and [4]. See Table 2 below: IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 13 Ensure that all partitions are unarmed Press the [#] hash key followed by the [INSTALLER CODE]. The default installer code is 9999 If a correct code has been entered the green READY indicator IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 14 AWAY indicator will extinguish. Repeat steps 2 - 6 until all the necessary locations and their sublocations have been programmed. Press the [#] hash key twice to exit from program mode. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 15 Once a final selection has been made enter the [ ] star key again to enter the selection. The AWAY indicator will extinguish and a long beep will indicate acceptance of a valid data entry. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 16 Program sub-location 1of location 1 - 16 to define the zone characteristics of each of the sixteen zones. There are 12 (twelve) zone types. Table 4 provides a location/zone cross-reference together with the default zone characteristics. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 17 / y r t i x o l l Table 5 (page 18) Provides a complete list of the different zone types together with a description of their characteristics. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 18 IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 19 Note: Select all the options for each zone. This is a bitmapped location. e l i e l i t l u IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...

  • Page 20: Cross Zoning

    To disable a reporting code a double zero (00) must be entered. The code transmitted when the zone is violated during an arm cycle or if a panic or 24 Hour Zone is violated. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 21 1 to 5. The second digit sets the output action. Refer to Table below for a list of actions. Refer to Section 17.6.4 for a detailed description for Programming Programmable Ouputs. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 22 The zone loop response is the period of time for which the zone must remain violated before a violation is registered. By default a Fixed Zone Loop Response of 100ms is used. See option 4 of location 38. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 23 A [0] will disable this location. Program zones as cross zones in Sub Location 2 of locations [1 - 16]. A single cross zone violated continuously for the time specified in Location 36 will also register an alarm condition. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 24 IDS816 INSTALLER MANUAL t i t t i t t l u IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 25 Provided the back up battery is in good condition, short AC power failures will not affect the functioning of the alarm system.Select the appropriate value from the table above. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...

  • Page 26: Power Led

    A trouble condition is indicated by a flashing POWER LED. The trouble condition can be viewed by holding down the [7] key for three seconds. See page 20 (Viewing Trouble Conditions) of the user manual. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 27 Sets the number of consecutive incorrect codes which will activate a keypad lockout. The keypad will remain locked for the time programmed in Location 44. Activating a keypad panic will unlock the keypad. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 28 Only a value of four or six may be programmed into this location. By default all codes are four digits in length. Note: The value programmed into this location has no effect on the download code. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 29 This code is reported when there is a tamper condition on any external device attached to the keypad bus. This code is reported when there is a fault on the keypad bus IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 30 This reporting code will be reported when the RF PIR battery voltage drops below 4V. This reporting code will be reported when the RF PIR battery voltage rises above 4V for 1 hour. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 31 Wired Zone Expander module. When selecting outputs, programmable outputs on the IDS816 alarm panel are addressed from ‘1’ to ‘5’. outputs on the Wired Zone Expander are addressed as ‘6’ and ‘7’. Please refer to the table below.
  • Page 32 Note: When connecting any device with a high current requirement to a programmable output, a suitable relay must be used. DO NOT connect such devices directly to the programmable outputs. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 33 IDS816 INSTALLER MANUAL l i a u l i l i a l i a IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 34 Enter a two digit value of the current day of the month. Valid range 01 - Enter the month as a value from 01 to 12. Enter the current year as a four digit value e.g. 2005. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 35 If the last week of the month is wanted program a five (5). This location is used for setting the Daylight Saving offset. Enter the number of minutes the clock will offset - Valid range 0 - 250. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...

  • Page 36: Event Log

    (single reporting) or to report independently to 2 central stations (dual reporting). The primary and secondary telephone numbers may be joined to provide for a single telephone number of 48 digits in length. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 37 Most reporting formats use a 4 digit account code. SIA format has the capability of using a 6 digit account code. Program a 6 into this location to enable six digit account code reporting. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 38 See Table for location 116. NOTE ON DUAL REPORTING When dual reporting is enabled it is possible to select two different formats which will be reported to each telephone number. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 39 A series of tones is transmitted to the phone which notifies the user that an alarm condition has occured. Pressing the [#] key on the phone will stop domestic dialling. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 40 This is especially useful when using Contact I.D or SIA formats. Instead of having to individually disable multiple locations it is possible to disable groups of reporting codes. These locations are bitmapped. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 41 IDS816 INSTALLER MANUAL l i a l i a IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 42 IDS816 INSTALLER MANUAL IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 43 A 4 second pause can be inserted at any point of the telephone number by entering a value of [15] - [MODE] then [5] To terminate a telephone number, program a [0] immediately following the last digit of the telephone number. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 44 In the event that the panel picks up the phone and no valid download log on sequence is received by the panel, the call will be terminated by the panel. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 45 This account code is only used when dual reporting is enabled. It is reported to Telephone Number 2 IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 46 ' r s ' r IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...

  • Page 47: Quick Arm

    If enabled this option prevents arming the panel after an alarm condition has occured. The panel can only be armed after the engineer has entered a valid installer code. A trouble condition will be displayed on the keypad. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 48 IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 49 ) t l The secondary entry delay applies to secondary entry/ exit zones. Once an entry has been initiated subsequent violations of any entry zone will NOT reset the entry time. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 50 This Bitmapped sublocation sets the days on which the partition will auto-disarm at the time programmed in sublocation 11. Note: Auto Disarm needs to be enabled per partition. See sublocation 4. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 51 This code is reported when the [P] key on a keypad is held down for two seconds. This code is reported when the [F] key on the keypad is held down for two seconds. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 52 See section 17.6.4 on page 31 for details on how to program the programmable outputs. The table below summarizes the partition specific events that can be assigned to the outputs. t i t f i r IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 53 This is a bitmapped sublocation where any programmable output can be programmed to clear (set low) on disarming. The IDS 816 provides for 32 user codes. These locations allow the installer to configure the user code properties. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 54 By default User Code 1 is assigned to Partitions 1 and 2. All other User Codes are assigned to Partition 1. t i t t i t t i t This is a bitmapped sublocation. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 55 If the siren is sounding and the siren is cancelled using a valid user code, a cancel code will be reported. A silent alarm or silent panic will not cause the cancel code to be reported. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 56 To disable scheduling an output ensure that all “days” are unselected. Either the time using the “hhmm” format when the output is to be SET HIGH. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 57 Enter the time using the “hhmm” format when the output is to be SET LOW. This bitmapped sublocation determines which day(s) an output can be scheduled to turn OFF. These locations allow the installer to setup the individual keypad properties. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...

  • Page 58: Keypad Options

    The Global Keypad Options will allow all sixteen zones to be displayed regardless of which partition they are in. Keypad zones are mapped according to Keypad I.D as shown in the table. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 59 RF device enter the Zone number followed by the [ ] star key. Tamper the RF device ( that you wish to add) to register it with the panel. Press the [#] key to exit location. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 60 This location unassigns RF Devices. To unassign an RF device enter its zone number followed by the [ ] star key. Press the [#] hash key to exit location. IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 61 IDS816 INSTALLER MANUAL t l u t l u t l u / l i t l u t l u l l a s t i u l i IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 62 IDS816 INSTALLER MANUAL u l i l i a . t t . t t l i a u l i l i a IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 63 IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 64 IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
  • Page 65 IDS816 INSTALLER MANUAL t i t t i t t l u t i t t l u t i t t l u e l l t l u IDS816 INSTALLER MANUAL NO. 700-283-02B ISSUED NOV 2004 VER 2.00...
