Auto Arm

The panel may be programmed to arm automatically at a pre-programmed time. Should the premises be
occupied at the time of auto-arming, a valid user code entered during the pre-arm delay will terminate the
arming sequence. The pre-arm delay is signalled by an exit beep.
NOTE: This can be enabled via the maintenance code, see page 32.

Disarming the Control Panel

4.

How to Disarm with a User Code

1. Enter the premises through a designated entry route. Entering via any other route will cause an alarm.
2. As soon as the Entry/Exit zone is violated, the entry delay will begin. The keypad buzzer will sound for
the duration of the entry period.
3. Press the [#] key and enter a valid [USER CODE].
4. Once the system disarms, the ARM LED will turn off and the keypad buzzer will stop sounding.
5. If no valid user code has been entered prior to the expiry of the entry delay period an alarm condition
will be registered.
6. If the entry period is too short, have your installer change the entry delay period.
NOTE: If a strobe (or flashing light) has been installed and an alarm condition is registered, the strobe will
continue flashing after the siren has stopped sounding. Entering a valid user code will cancel the strobe.

How to Disarm Using a Key-switch or Remote

1. Activate the remote or key-switch. (The blue button on the IDS remote, unless otherwise programmed).
2. The system will disarm and the armed LED indicator (if installed) will turn off. If the siren toot on disarm
option is enabled, the siren will provide a double toot when the panel is disarmed.

Bypassing Zones

5.

The term BYPASS is used to describe a zone that has been deactivated; i.e. violation of a bypassed zone,
whilst the system is armed, is ignored and will not cause an alarm condition.

Once the system is armed, it is not possible to bypass zones.

All bypassed zones will be automatically cancelled each time the panel is disarmed and must be re-
bypassed before the next arming.
 To permanently bypass ones, create a stay profile and the zone. Refer to section 19 Stay Zones page 24.

Bypassing/Un-bypassing a Zone
LED Keypad
Hold down the [9] key until the beep, then enter [USER CODE] [*] [ZONE NUMBER] [*] [#]
1. Ensure that the panel is not armed (ARM LED OFF).
2. To enter bypass mode, hold down the [9] key for until the keypad buzzer sounds. The AWAY LED will
flash.
3. Enter [USER CODE] followed by the [*] key. The bypassed zone LEDs will be on.
4. The READY LED will come on.
5. Entering a zone number [ZONE NUMBER] followed by the [*] key will toggle the corresponding LED. For
example, [2] [*] will turn LED 2 on (if it was off) and off (if it was on). The READY LED will come on.
6. Turn on the LEDs corresponding to the zones you need to bypass. The zone LEDs should now indicate
only the zones that require bypassing.
7. Press the [*] key to page through to see zones 17-32. If you press the [*] key again, you will view zones
33-48. And press the [*] key again to see zones 49-64.
8. After each star press you can repeat steps 4-5.
9. Once satisfied with your selection, press the [#] key to exit the bypass mode.
LCD Keypad
Hold down [9] until the beep, then enter [USER CODE] [*] [ZONE NUMBER] [*] [*] [#]
1. Ensure the panel is not armed.
2. To enter bypass mode, hold down [9] until the beep.
3. The LCD display reads 'User Code + *'.
4. Enter the [USER CODE] followed by the [*] key.
5. The LCD display reads 'Zone Number + *'.
14
[#] [USER CODE]
700-398-01J X-Series User Manual Issued for version 2.8x
