Inhep Digital Security IDS 800 Installer Manual

Versatile, state of the art, microprocessor based, eight zone alarm panel
Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IDS 800 and is the answer not in the manual?

Questions and answers

Related Manuals for Inhep Digital Security IDS 800

Summary of Contents for Inhep Digital Security IDS 800

  • Page 2 IDS800 INSTALLER MANUAL Summary of Operation & + [( ( ( ( ( ] e l i [( ( ( ( ( ] + + [( ( ( ( ( ] + [( ( ( ( ( ] + [( ( ( ( ( ] IDS800 INSTALLER MANUAL NO.

  • Page 3: Table Of Contents

    IDS800 INSTALLER MANUAL Contents Introduction to the IDS800 ..........5 1.1 Features ................5 Installation and Wiring ..........6 End-of-Line Resistors/Tamper per Zone ....7 Connecting the Telephone Communicator ....8 Programmable Outputs ..........8 Expansion Board ............9 The Key-Switch or Remote Control Unit ....10 Additional Technical Data ...........

  • Page 4: Table Of Contents

    IDS800 INSTALLER MANUAL Figures Figure 1: Connection Diagram ..........6 Figure 2: Tamper per Zone Connection ......7 Figure 3: Resistors user for Tamper per Zone ....8 Figure 4: Programmable Output Configuration ....9 Figure 5: Expansion Board Connection ......9 Figure 6: Strobe Output Sequence ........

  • Page 5: Introduction To The Ids800

    IDS800 INSTALLER MANUAL 1. Introduction to the IDS800 The IDS800 is a versatile, state of the art, microprocessor based, eight zone alarm panel. Most features are optional and may be programmed either directly through the keypad or via the telephone system, using the IDS download software and appropriate modem.

  • Page 6: Installation And Wiring

    IDS800 INSTALLER MANUAL 2. Installation and Wiring Please refer to Figure 1: Connection Diagram and familiarise yourself with the following sections. Figure 1: Connection Diagram - without tamper per zone Dialler Board LINE TELKOM RADIO AUXILLIARY TRANSMITTER EARTH EARTH OUTPUTS LINE COMMUNICATOR Position of...

  • Page 7: End-Of-Line Resistors/Tamper Per Zone

    IDS800 INSTALLER MANUAL 3. End-of-Line Resistors/Tamper per Zone All zones are end-of-line supervised. Any unused zones must also be terminated with the appropriate resistor. The end of line resistor should be placed inside or as close to the sensor as possible. If the zones are not programmed to report tamper by zone i.e.

  • Page 8: Programmable Outputs

    IDS800 INSTALLER MANUAL input and ground) and the 4K7 resistor is used as the normal end- of-line resistor. The colour codes for the 12K and 4K7 resistors are as seen in Figure 3 below. Figure 3: Resistors used for Tamper per Zone Yellow Red Brown Orange Purple...

  • Page 9: Expansion Board

    IDS800 INSTALLER MANUAL Figure 4: Programmable Output Configuration 1000R 1000R 1000R Output 1 Output 2 Output 3 6. Expansion Board Attached to the keypad bus, in parallel with the keypad, is an optional expansion board which allows for the following: Programmable outputs 4 and 5 which function as per the values programmed into locations 22 - 40 and locations 159 - 166.

  • Page 10: Additional Technical Data

    IDS800 INSTALLER MANUAL 7. The Key-Switch or Remote Control Unit A momentary key-switch or non-latching remote control receiver may be connected to any zone to allow remote arm/disarm capability and/ or remote panic. If a key-switch or remote control unit is used, a 3K3 resistor must be connected between the zone input and ground.
  • Page 11 IDS800 INSTALLER MANUAL supervised zone and requires a normally open panic switch. If using this panic zone connect a normally open panic switch between the PAN terminal and the GND terminal. If this zone is not used leave the terminal open circuit. A door LED may be connected to the keypad.

  • Page 12: Event Log

    IDS800 INSTALLER MANUAL 9. Hardware Reset Switch In the event that the installer code is lost, it is possible to reset the panel to its factory default values using the hardware reset switch labelled SW1 on the main PC board. Provided that the reset switch has not been disabled (see location 21) the panel may be defaulted by removing both battery and AC power from the panel, and then reapplying the power ( AC /battery) while depressing the switch.

  • Page 13: Dialler Progress Mode

    IDS800 INSTALLER MANUAL 11. Dialler Progress Mode When the panel sends data to a central station, the keypad zone ’s may be used to display the “progress” of such communication. To view the communication status proceed as follows: Hold down the [0] key until the keypad buzzer sounds twice. Press the [9] key.

  • Page 14: Programming Instructions

    IDS800 INSTALLER MANUAL 13. Programming Instructions 13.1 Introduction The panel may be programmed either using the keypad or using the up/download software. Programming the panel by means of the keypad is explained in the following sections of this manual. For information on programming the panel using the up/download software refer to the manual pertaining to the software.

  • Page 15: Programming The Panel

    IDS800 INSTALLER MANUAL Table 3: Binary Representation ) ) ) ) ) ) ) ) ) ) ) ) ) ) ) ) u l l 13.3 Programming the Panel For all programming procedures, the [(] (star) key functions as the enter key and the [#] (hash) key functions as a clear key to clear incorrect or unintended entries, as a back space and to exit the programming mode.

  • Page 16: Program Location Summary

    IDS800 INSTALLER MANUAL location value, press the [#] key. The READY indicator will continue flashing and the AWAY indicator will extinguish. If the data value has been changed, the buzzer will give a long beep indicating that a valid entry has been stored. 10.

  • Page 17: Table 4: Location/ Zone Defaults

    IDS800 INSTALLER MANUAL Program locations 1 to 8 define the zone characteristics of each of the eight zones. Each zone can be programmed to function in one of eleven modes. Table 4 provides a location/zone cross-reference together with the default zone characteristics. Table 4: Location/Zone Defaults / y r t i x...

  • Page 18: Table 5: Programmable Zone Types

    IDS800 INSTALLER MANUAL Table 5: Programmable Zone Types t a l t a l t i x t i x t a l t i x t i n t i x u l i t i x t i x l l i f I .
  • Page 19 IDS800 INSTALLER MANUAL t a l e l i t s i e l i t a l e l i e l i / y r t i x / y r t i x t a l t n i y l t .
  • Page 20 IDS800 INSTALLER MANUAL > > > t l u > > > > > > > > > > > > > > If the Entry/ exit delay is enabled, the panel can be programmed to allow arming with violated Follower and/ or Entry/ exit zones. NOTE: For all values programmed into location 9 the panel will only arm if the indicator is illuminated.
  • Page 21 IDS800 INSTALLER MANUAL . n i . n i . n i . n i . n i . n i ) t l . n i . n i . n i . n i . n i The secondary entry delay applies to the secondary entry/exit zone. If a primary entry zone is violated, the primary entry delay is activated.
  • Page 22 IDS800 INSTALLER MANUAL > t l u > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > The quick arm option allows the user to arm the panel by holding down the [1] key until the keypad beeps.
  • Page 23 IDS800 INSTALLER MANUAL condition to be registered. The Engineer reset function determines whether the panel can be armed after an alarm condition has been registered. This can be used to force the customer to have the system inspected in the event of an alarm condition.
  • Page 24 IDS800 INSTALLER MANUAL e l i t l u e l i The value programmed into this location only affects the keypad panic. e l i t l u e l i If a zone is programmed as a silent instant zone, an alarm condition as a result of a violation of this zone would be silent regardless of the value programmed into this location.
  • Page 25 IDS800 INSTALLER MANUAL . n i . n i . n i . n i . n i . n i . n i . n i ) t l . n i . n i . n i The siren time out period is the period of time for which the siren will sound after an alarm condition is registered.
  • Page 26 IDS800 INSTALLER MANUAL . n i . n i . n i ) t l . n i . n i . n i . n i . n i . n i . n i . n i . n i .
  • Page 27 IDS800 INSTALLER MANUAL This is the period of time allowed to enter and disarm the panel before an alarm condition is registered. The entry delay begins after the violation of a primary entry/exit zone. During this period it is permissible to violate follower zones without causing an alarm condition provided that an entry/exit zone was violated first.

  • Page 28: Table 6: Output Options

    IDS800 INSTALLER MANUAL Table 6: Output Options The strobe and fire-detect outputs may only be programmed with [0] to [5] i.e. a pulsed output. The second phone number dialled output can only be programmed with values [1] - [5] ([0] will disable the output). Table 7: Location default values y t i l i a...

  • Page 29: Figure 6: Strobe Output Sequence

    IDS800 INSTALLER MANUAL Programming Example Program output No. 2 to report open and close, with close HIGH and open LOW : It will be noted from Table 7 that output No. 2 is already assigned as the alarm output. This condition first needs to be disabled from output 2 before a new condition may be assigned otherwise CLOSE OPEN will all be programmed to Programmable Output 2.

  • Page 30: Figure 7: Fire Detect Output Sequence

    IDS800 INSTALLER MANUAL Figure 7: Fire Detect Output Sequence NOTE Since multiple conditions may be programmed to a single output It is essential to ensure that no unwanted conditions are assigned to the same output. Provision is made for the panel to dial different phone numbers (locations 48-63 for primary number and 64-79 for the secondary number).
  • Page 31 IDS800 INSTALLER MANUAL t l u l a i n i l l i t l a i n i l l a i n i l e l l o l l i g i . s t l a i n i l l a i n i l...
  • Page 32 IDS800 INSTALLER MANUAL If single base reporting is selected, program the following locations: Locations 43 - 46 Primary Account Code Location 47 Primary Communicator Code Locations 48 - 63 Primary Phone Number Locations 64 - 79 Secondary Phone Number If dual reporting is selected, program the following locations: Locations 43 - 46 Primary Account Number Location 47...
  • Page 33 IDS800 INSTALLER MANUAL Example: The desired account code is 14 (i.e. 0014) Enter [10] into location 43. Enter [10] into location 44. Enter [1] into location 45. Enter [4] into location 46. t l u ) y t ) y t n i l c i t n i l...
  • Page 34 IDS800 INSTALLER MANUAL NOTES ON CONTACT ID. If the panel has been programmed to use the Contact ID reporting format (i.e. location 47=6) it is not necessary to program the reporting codes. All codes will be reported by default. Table 8 contains a list of standard (default) Contact ID reporting codes.

  • Page 35: Table 8: Standard Contact Id Reporting Codes

    IDS800 INSTALLER MANUAL Table 8: Standard Contact ID reporting codes t i r c t i c t i t a l t a l l i a t a l t a l / y r t i x t a l t a l t a l...

  • Page 36: Table 9: Alarm Reporting Codes

    IDS800 INSTALLER MANUAL Table 9: Alarm reporting codes / y r t i x EXAMPLE Assuming for a given installation it is required to differentiate between entry/exit, interior and general burglary zones, and assuming that zone 1 is a front door (entry/exit zone), zone 2 is an interior PIR (interior zone) and zone 3 is a general burglary zone.
  • Page 37 IDS800 INSTALLER MANUAL 64-79. Follow the phone number with an 8 second delay by programming a [15] into the 2 locations immediately following the phone number (see locations 48-63). Program a [6] in the location immediately after the 8 second delay.
  • Page 38 IDS800 INSTALLER MANUAL The panel would be programmed as follows: s t i After a successful communication attempt caused by a zone 1 violation the pager will display 012301 NOTES ON DOMESTIC REPORTING: Domestic reporting will dial both phone numbers as programmed into locations 48-63 and 64-79.
  • Page 39 IDS800 INSTALLER MANUAL NOTES ON PROGRAMMING TELEPHONE NUMBERS: To dial a “0” program a [10] into the location. To dial a “(” program an [11] into the location. To dial a “#” program a [12] into the location. To create a 12 second pause in the number program a [14] into the location.
  • Page 40 IDS800 INSTALLER MANUAL These locations contain the secondary telephone number that may be up to sixteen digits long. The same procedures apply as for the Primary Telephone Number. Communicator Reporting Codes (Locations 80-116) With the exception of Contact ID and Sescoa Superfast, all other communications formats are 4 x 2 reporting formats i.e.
  • Page 41 IDS800 INSTALLER MANUAL This code will be reported if the panic button on the keypad is pressed. The keypad tamper code will be reported if multiple attempts are made to disarm the panel using the wrong user code. The code will be reported after 16 incorrect keystrokes i.e.
  • Page 42 IDS800 INSTALLER MANUAL The low battery condition will be reported if the battery voltage drops below 10 volts. If the battery fuse blows then the battery will discharge and a low battery condition will be reported, even if the AC power is present.
  • Page 43 IDS800 INSTALLER MANUAL system (See Users Manual). EXAMPLE If an open code of B (11) is programmed and the master user code is used to disarm the system, the 2 digit reporting code would be B1 indicating an open by user 1. NOTE If the system is disarmed by means of a key or remote using an arm/ disarm zone the system will report open by user 13.
  • Page 44 IDS800 INSTALLER MANUAL bypassed zone. The zone number will be appended to this reporting code to provide the 2 digit reporting code. The zone tamper code will only be reported if the zone tamper function has been enabled, see location 11. The zone number will be appended to this reporting code to provide the 2 digit reporting code.
  • Page 45 IDS800 INSTALLER MANUAL NOTE Entering [0] into this location will disable the dialler. e l l : t l The installer’s ID code is used by the installer to enter the program mode. This may be changed by entering a new 4 digit code into these 4 locations.
  • Page 46 IDS800 INSTALLER MANUAL cycle before it is automatically bypassed. The count will be twice the value entered. The maximum value of 15 may be entered, corresponding to 30 violations required to force the zone to bypass. Disable swinger shutdown by entering [0] in this location. t l u The zone loop response is the period of time for which the zone must be violated before a violation is registered.
  • Page 47 IDS800 INSTALLER MANUAL This time delay period applies to location 134. If the panel is armed and the number of violations programmed into location 134 occurs within this time delay, an alarm condition will register. Program a value from [0] to [15]. Multiply the value of the entry by 10 seconds to calculate the delay time.
  • Page 48 IDS800 INSTALLER MANUAL > > > > > > > > > > > > t l u > This location determines whether Communication failure, keypad tamper or engineers reset are displayed as trouble conditions. Should the display be disabled no trouble condition will be shown i.e. the power LED will not flash and no trouble condition shown when entering trouble viewing mode.
  • Page 49 IDS800 INSTALLER MANUAL The time period between auto-test reports is programmed using this location. The time period is incremented in 24 hour increments with the shortest time period being 24 hours. The maximum value which may be programmed into this location is This location programs the number of rings before the panel picks up the telephone line and attempts to up/download.
  • Page 50 IDS800 INSTALLER MANUAL This account code is used if the panel is communicating to two base stations and will be transmitted to the secondary phone number. See Locations 43 - 46 for information regarding the programming of these locations. This communicator format is used if the panel is communicating to two base stations and will be transmitted to the secondary phone number.
  • Page 51 IDS800 INSTALLER MANUAL SEE LOCATIONS 22 - 44 and TABLE 6 A programmable output will be activated when a zone is violated. Set System Time, Auto-Test Time, Automatic Arm Time All time values must be entered as a 4 digit value in hours and minutes in a 24 hour format i.e.

  • Page 52: Trouble Conditions Summary

    IDS800 INSTALLER MANUAL programmed into location 801, the auto test would be sent every seven days at 2:00pm. : t l This location sets the time at which the panel will automatically arm every day (if enabled). The auto arm feature is disabled by entering an invalid time greater than 2400 e.g.
