5. A valid entry is confirmed by a long beep. An invalid entry will be signalled by means of an error beep (3
short beeps). If an error beep occurs, press the [#] key to clear all previous entries and repeat steps 1-4.
6. Further codes can be added by repeating step 4 above. When a user code is added, it is stored in the first
available user slot.
7. Press the [#] key to exit the User Program Mode.
NOTE: The new user code will be added to the first available slot. A slot is just a place holder number for a user
code. I.e. User code 1 is in slot 1; all the way to user code 128 in slot 128.
Edit a Selected User Code – Option 1
LED Keypad
Hold down the [*] key until the beep, then enter [MASTER CODE] [*] [1] [*] [OLD CODE] [*] [NEW CODE] [*]
1. Enter the User Program Mode as per steps 1 to 4 in section 0.
2. Press the [1] key followed by the [*] key to select programmable option 1.
3. The READY and ARM LEDs flash simultaneously.
4. Enter the [OLD CODE] which is to be edited followed by the [*] key.
5. The READY and AWAY LEDs flash simultaneously, and the ARM LED will be on.
6. Enter the [NEW CODE] followed by the [*] key.
7. The READY and ARM LEDs flash simultaneously.
8. To edit other codes repeat steps 4 - 7.
9. Press the [#] key to exit the current option.
10. Press the [OPTION NUMBER] followed by the [*] key for the next option, or the [#] key again to exit user
programming.
LCD Keypad
Enter the User Program Mode as per steps 1 - 4 of section User Program Mode.
1.
The LCD display reads 'Option Menu', 'Add User Code'.
2.
To select menu option 1 – 'Edit User Code', press the [1] key or alternatively use the [PANIC] or [MED]
3.
keys to scroll through the list of programmable options until you reach the option you want.
Press the [*] key.
4.
The LCD display reads 'Old Code + *'.
5.
Enter the [USER CODE] you wish to edit followed by the [*] key.
6.
The LCD display reads 'New Code + *'.
7.
Enter the [NEW CODE] followed by the [*] key. To move the cursor within the NEW CODE, use the
8.
[PANIC] or [MED] keys.
To edit other codes repeat steps 5 - 7.
9.
Press the [#] key to exit the User Program Mode.
10.
Delete a User Code – Option 2 (Code Known)
LED Keypad
Hold down the [*] key until the beep, then enter [MASTER CODE] [*] [2] [*] [USER CODE] [*] [#]
1. Enter the User Program Mode as per steps 1 to 4 in section 0.
2. Press the [2] key followed by the [*] key to select programmable option 2.
3. The READY and ARM LEDs flash simultaneously.
4. Enter the [USER CODE] to be deleted followed by the [*] key. "Deleting" the code in slot one will
reprogram it to 1234.
5. The READY and ARM LEDs flash simultaneously.
6. Further codes may be deleted by repeating step 4.
7. Press the [#] key to exit the current option.
8. Press the [OPTION NUMBER] followed by the [*] key for the next option, or the [#] key again to exit user
programming.
LCD Keypad
Enter the User Program Mode as per steps 1 - 4 of section User Program Mode.
1.
The LCD display reads 'Option Menu', 'Add User Code'.
2.
18
[*] [MASTER CODE] [*] [1] [*] [OLD CODE] [*] [NEW CODE] [*] [#]
[*] [MASTER CODE] [*] [2] [*] [USER CODE] [*] [#]
