Reading Binary Values

Values within a data program location will be displayed by the zone LEDs in binary coded decimal format i.e.
zone LEDs 1-4 indicate units (ones) and zone LEDs 5-8 indicate tens (tens), and so on. To read a binary value on
the keypad, add up the values represented by each lit LED as shown in Table 2.
Table 2: Values Represented by each Zone LED
EXAMPLE:
Imagine the following zone LEDs are on: Zone 1, Zone 3 and Zone 5.
Units are represented by the sum of Zone 1 and Zone 3 (i.e. 1 + 4).
Tens of units are represented by the value of Zone 5 (i.e. 1 x ten).
Therefore, the displayed value is (1+4) + (10) = 15.
Values within a time program location are displayed in a similar format as per Table 3.
Table 3: Binary Coded Decimal Four Digit Display
Zone LED
1
2
3
4
5
6
7
8
Using an LCD keypad means that data and time information can be read directly without a need to convert.

Entering Data on an LED Keypad

Data is easily entered on a keypad. Below is a list of keys and their functions.
[*] – This key is used as an enter key, to confirm the data that you have inputted. It is also used to scroll to the
next sub-location.
[#] – This key is used to clear data that is incorrect. It can also be used to exit a programming option.
[F] – This key is used if there is a fire emergency. If programmed to do so, the fire reporting code will be sent to
your monitoring company.
[M] – This key is used if there is a medical emergency. If programmed to do so, the medical reporting code will
be sent to your monitoring company.
[P] – This key is used if there is an emergency situation that requires emergency personnel to respond. A panic
alarm will be transmitted to your monitoring company.
[0] to [9] – Keys marked 1 through 9, and including 0, are used to input data into the programming options.
10
Zone LED Value
Zone 1 1
Zone 2 2
Zone 3 4
Zone 4 8
Zone 5 1
Zone 6 2
Zone 7 4
Zone 8 8
Calculation Unit
(x 1 = 1)
(x 2 = 0)
m
(x 4 = 4)
(x 8 = 0)
(x 1 = 1)
(x 2 = 0)
M
(x 4 = 4)
(x 8 = 0)
700-398-01J X-Series User Manual Issued for version 2.8x
Digit Zone LED
Zone 9
Zone 10
Units
Zone 11
Zone 12
Zone 13
Zone 14
Tens
Zone 15
Zone 16
Zone LED Calculation
9 (x 1 = 1)
10 (x 2 = 2)
11 (x 4 = 4)
12 (x 8 = 0)
13 (x 1 = 1)
14 (x 2 = 0)
15 (x 4 = 1)
16 (x 8 = 0)
Value Digit
1
2
Hundreds
4
8
1
2
Thousands
4
8
Unit
s
Mm:Ss
= 54:43
m = LEDs 4 through 1
M = LEDs 5 through 8
S
s = LEDs 12 through 9
S = LEDs 16 through 13
