Alarm Memory

6.
The Alarm Memory displays any zones that were violated, tampered with, or bypassed during the last arm
cycle. A flashing ARM LED will notify you of an alarm. To view the alarm memory, disarm the panel and
continue as follows:
1. Hold down the [0] key until the keypad buzzer sounds.
2. The POWER LED will turn off and the keypad buzzer will sound briefly.
3. Zone LEDs that are on show which zones were violated during the last armed period.
4. Press the [1] key followed by the [*] key to return to violated zones.
5. Press the [2] key followed by the [*] key to display zones that were bypassed.
6. Press the [3] key followed by the [*] key to display which zones were tampered with.
7. Press the [6] key followed by the [*] key to view the event log. (Only on the LCD keypad).
8. Press the [*] key to page through to see zones 17-32. If you press the [*] key again, you will view zones
33-48. And press the [*] key again to see zones 49-64.
9. After each star press you can repeat steps 4-7 to view the status of the zones.
Note that the alarm memory is erased at the beginning of each arm cycle.

Event Log

7.
Events can be viewed on an LCD keypad only, displayed as follows:
HH:MM
DD/MM/YYYY
eeeeeeeeee p ddd
NOTE:

The system time and date need to be setup correctly in order for the event log to pull the correct
information. These can be setup in options 40 and 41.

Pressing [6] followed by [*] after the event log viewing is already active will reset the menu to the most
recent event.
Each event description will be followed by two numbered fields if further data is applicable to that event. The
first number is the partition number within which the event occurred. The second number will either be the
zone or user number associated with the event type.

Master User Program Options

8.
The IDS X-series Alarm Panels have 128 programmable user codes. By default, user code 1 is the Master User
Code that contains a pre-programmed 4-digit code of 1234 and belongs to all partitions.
NOTE: User codes may be 4 (default) or 6 digits long (with a default code of 123456). This is a programmable
feature. Check with your installer to verify which option has been programmed.

Accessing the Master User Program Options

The IDS X-series Panels have a friendly programmable interface that allows you to add, modify or delete user
codes. See Table 5 for a summary of programmable options. The programmable interface is accessed by
entering the USER PROGRAMMING MODE where it is possible to change user options.
Table 5: User Programming Options
Options
Option 0 - 13
Option 14 - 19
Option 20 - 29
Option 30
Option 31
Option 32 - 34
Option 40
Option 41
16
Hold down the [0] key until the beep
(HH:MM = event time MM-DD- YYYY = event date)
(eeeeeeeeee = event description p = partition event occurred in (if applicable)
ddd = event data(if applicable)
Summary of Programmable Options
Allows for the addition and editing of user codes and their properties
Xwave2 bi-directional wireless and remote transmitter options
Allows for adding of remotes
Zone Naming. Please consult the X-series LCD Keypad Manual
Language selection(Keypad version 2.02 and above)
aXess control setup
Allows for the editing of the time
Allows for the editing of the date
700-398-01J X-Series User Manual Issued for version 2.8x
