6�2

Design features PE3 (version with cooling jacket)

1
Stainless steel lifting hoop
2
Lid assembly
3
Cable gland
4
Upper bearing - cylindrical roller 12
bearing
5
Coolant fill plug
6
Cooling jacket
7
Motor housing
8
Lower bearing housing
9a
Leakage sensor (DI) 50 Hz
EN 5675-L
1
2
3
4
5
6
7
8
9a
10
11
12
13
9b
Leakage sensor (DI) 60 Hz
10
Lipseal
11
Seal holding plate
Mechanical seals
13
Venting plug
14
Terminal block
15
Pressure test point
16
Upper bearing housing
17
Motor with thermal sensors
18
Stainless steel shaft
16
14
15
5
17
18
19
9b
20
21
22
23
24
25
26
27
19
Lower bearing - double row
20
Inspection chamber
21
Coolant impeller
22
Flow deflector
23
Coolant drain plug /
pressure test point
24
Seal chamber
25
Volute
26
Impeller - Contrablock version
27
Bottom plate adjustment screw
9
