Due to spacing differences of the IPE cabinet at the local site and the cabinet at the remote
site, two versions of each card are available.
The MCR system also consists of three new cable assemblies. These assemblies are the LMI
Multi-I/O cable assembly (NT5D85), LMI/LMX Multi-I/O cable assembly (NT5D86), and the
RMI Multi-I/O cable assembly (NT5D87).

Physical description of cards

The LMI and LMX cards are double-wide line cards, each taking up two card slots. All three
card faceplates have ejector tabs to facilitate insertion and removal.
The LMI, LMX, and RMI faceplates are illustrated in
faceplate on page 22,
4: RMI (NT5D67) faceplate
Mini-Carrier Remote Fundamentals
Figure 3: LMX (NT5D65/NT5D69) faceplate
on page 24, respectively.
Figure 2: LMI (NT5D64/NT5D68)
on page 23, and
Physical architecture
Figure
March 2013 21
