Champion Model 80 DRHDPW Specifications

44" single tank with 36" heavy duty prewash high-temperature rack conveyor dishwashing machine with dual stage rinse
Hide thumbs Also See for Model 80 DRHDPW:
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
STANdARd FeATuReS
• ENERGY STAR® Qualified
•
Exclusive DualRinse Technology
•
Dual-pawl cradle drive system
•
One-piece cast stainless steel upper
& lower spray arm assemblies
•
Internal removable scrap basket and
two-piece scrap screen
•
Standard vertical opening accommodates
18" x 26" sheet pans
•
Wide 26" leakproof doors, internally-fitted
•
Anti-jam conveyor drive system
•
Energy Sentinel (Idle pump shut-off)
•
Convenient top-mounted controls
•
Automatic tank fill
•
Common utility connections
•
Door safety switch
•
Door activated drain closure
•
Enclosure panels (front and sides)
•
Splash shields
•
Low-water tank heat protection
•
Rinse-saver device
•
Stainless steel heavy-gauge construction,
including base and feet
•
Electric tank heat
•
Prewash pump 1 Hp motor
•
External prewash scrap basket
•
Wash pump 2 Hp motor
•
Stainless steel pump and impeller
•
Single-point electrical connection
The DualRinse feature offers the
Lowest Water/Utility/Chemical Consumption
circulating a generous 300+ gallons
of water for
Good Results
Champion Industries, Inc.
2674 N. Service Road,
Jordan Station, Ontario, Canada L0R 1S0
Tel: 800/263-5798 Fax: 905/562-4618
(1M) 2/05 Printed in U.S.A.
while
Consistently
Project
Item No.
Quantity
Model 80 dRHdPW
44" Single Tank with 36" Heavy Duty Prewash
Shown with Vent Cowl
and Damper Options
SPeCIFIeR STATeMeNT
Specified unit will be Champion Model 80 DRHDPW
high temperature dual rinse rack conveyor dishwashing
machine with 36" prewash. Constructed of Type 304
stainless steel and measuring 80" long with 20-3/4"
vertical opening. Features top mounted control cabinet;
upper and lower one-piece stainless steel spray arm
assemblies, removable internal scrap basket with
two-piece scrap screen, external prewash scrap basket.
Large 26" access doors with front access and double-
hook safety latch. Anti-jam conveyor drive system.
1 year parts and labor warranty.
High Temperature Rack
Conveyor Dishwashing Machine with
Dual Stage Rinse
Champion Industries, Inc.
P. O. Box 4149, Winston-Salem, NC 27115
Tel: 800/532-8591 Fax: 336/661-1979
www.championindustries.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Model 80 DRHDPW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Champion Model 80 DRHDPW

Summary of Contents for Champion Model 80 DRHDPW

  • Page 1 Shown with Vent Cowl and Damper Options SPeCIFIeR STATeMeNT Specified unit will be Champion Model 80 DRHDPW high temperature dual rinse rack conveyor dishwashing machine with 36” prewash. Constructed of Type 304 stainless steel and measuring 80” long with 20-3/4”...
  • Page 2 • Integrated design saves floor space leSS IS MoRe WITH CHAMPIoN’S duAl RINSe Model 80 dRHdPW Check our NSF listings and you’ll see the 80 DRHDPW offers the lowest water consumption in its class with less than .54 US gallons per rack. Water consumption this low means energy savings too. Our 40°F rise booster only requires 12 kW and 70°F rise is only 22 kW.
  • Page 3 25" 5/8" 7-1/2" 2-1/4" 21" Champion Industries, Inc., P. O. Box 4149, Winston-Salem, NC 27115 • 800/532-8591 • Fax: 336/661-1979 • www.championindustries.com 2674 N. Service Road, Jordan Station, Ontario, Canada L0R 1S0 • 800/263-5798 • Fax: 905/562-4618 96" 80" 36"...

  • Page 4: Front View

    1-3/4" 16" 5/8" 2-1/4" 21" Champion Industries, Inc., P. O. Box 4149, Winston-Salem, NC 27115 • 800/532-8591 • Fax: 336/661-1979 • www.championindustries.com 2674 N. Service Road, Jordan Station, Ontario, Canada L0R 1S0 • 800/263-5798 • Fax: 905/562-4618 96" 80" 8"...

  • Page 5: Specifications

    (by others) in common water supply line at service connection. Due to an ongoing value analysis program at Champion, specifications contained in this catalog are subject to change without notice. Champion Industries, Inc., P. O. Box 4149, Winston-Salem, NC 27115 • 800/532-8591 • Fax: 336/661-1979 • www.championindustries.com TABle B - Machine &...

  • Page 6: Options And Accessories

    Two-point electrical connection Due to an ongoing value analysis program at Champion, specifications contained in this catalog are subject to change without notice. Champion Industries, Inc., P. O. Box 4149, Winston-Salem, NC 27115 • 800/532-8591 • Fax: 336/661-1979 • www.championindustries.com Model MRC 180 180°...
