Champion Model 44 DR Specifications

STaNdaRd FeaTUReS
ENERGY STAR® Qualified
•
• Exclusive DualRinse Technology
• Dual-pawl cradle drive system
• One-piece cast stainless steel upper
& lower spray arm assemblies
• Internal removable scrap basket and
two-piece scrap screen
• Standard vertical opening accommodates
18" x 26" sheet pans
• Wide 26" leakproof doors, internally-fitted
• Anti-jam conveyor drive system
• Energy Sentinel (Idle pump shut-off)
• Convenient top-mounted controls
• Automatic tank fill
• Common utility connections
• Door safety switch
• Door activated drain closure
• Enclosure panels (front and sides)
• Splash shields
• Low-water tank heat protection
• Rinse-saver device
• Stainless steel heavy-gauge construction,
including base and feet
• Electric tank heat
• Wash pump 2 Hp motor
• Stainless steel pump and impeller
• Single-point electrical connection
The DualRinse feature offers the
Lowest Water/Utility/Chemical Consumption
while circulating a generous
300+ gallons of water for
Consistently Good Results
Champion industries, inc.
2674 N. Service Road,
Jordan Station, Ontario, Canada L0R 1S0
Tel: 905/562-4195 Fax: 905/562-4618
(1M) 5/08 Printed in U.S.A.
Project
item No.
Quantity
Model 44 dR
Conveyor Dishwashing Machine with
Shown with Vent Cowl
and Damper Option
SPeCIFIeR STaTeMeNT
Specified unit will be Champion Model 44 DR high
temperature dual rinse rack conveyor dishwashing
machine. Constructed of Type 304 stainless steel
and measuring 44" long with 20-3/4" vertical
opening. Features top mounted control cabinet;
upper and lower one-piece stainless steel spray arm
assemblies, removable internal scrap basket with
two-piece scrap screen. Large 26" wash door with
front access and double-hook safety latch. Anti-jam
conveyor drive system.
1 year parts and labor warranty.
44" Single Tank
High Temperature Rack
Dual Stage Rinse
Champion industries, inc.
P. O. Box 4149, Winston-Salem, NC 27115
Tel: 336/661-1556 Fax: 336/661-1979
www.championindustries.com
