Champion Model 84 Specifications

sTandard FeaTUres
• ENERGY STAR® Qualified
• Dual-pawl cradle drive system
• One-piece cast stainless steel upper & lower
spray arm assemblies
• Internal removable scrap baskets and
two-piece scrap screens
• Standard vertical opening accommodates
18" x 26" sheet pans
• Wide 26" leakproof doors, internally-fitted
• Anti-jam conveyor drive system
• Energy Sentinel (Idle pump shut-off)
• Convenient top-mounted controls
• Automatic tank fill
• Common utility connections
• Door safety switch
• Door activated drain closure
• Enclosure panels (front and sides)
• Splash shields
• Low-water tank heat protection
• Rinse-saver device
• Stainless steel heavy-gauge construction,
including base and feet
• Electric tank heat
• Wash/rinse pump 3 Hp motors
• Stainless steel pump and impeller
• Single-point electric connection
Champion Industries, Inc.
2674 N. Service Road,
Jordan Station, Ontario, Canada L0R 1S0
Tel: 905/562-4195 Fax: 905/562-4618
(3M) 9/06 Printed in U.S.A.
Project
Item No.
Quantity
Shown with Vent Cowl and
Damper Option
sPeciFier sTaTeMenT
Specified unit will be Champion Model 84 high
temperature rack conveyor dishwashing machine.
Constructed of Type 304 stainless steel and measuring
84" long with 20-3/4" vertical opening. Features top
mounted control cabinet; upper and lower one-piece
stainless steel spray arm assemblies, removable internal
scrap baskets with two-piece scrap screens. Large 26"
front access doors with double-hook safety latch. Anti-
jam conveyor drive system.
1 year parts and labor warranty.
Model 84
84" Two Tank
High-Temperature
Rack Conveyor Dishwashing Machine
Champion Industries, Inc.
P. O. Box 4149, Winston-Salem, NC 27115
Tel: 336/661-1556 Fax: 336/661-1979
www.championindustries.com
