Champion Model 44 DRWS Specifications

44" single tank water saver high temperature rack conveyor dishwashing machine with dual stage rinse
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

STaNdaRd FeaTUReS
• ENERGY STAR® Qualified
•
Exclusive DualRinse Technology
•
Dual-pawl cradle drive system
•
One-piece cast stainless steel upper
& lower spray arm assemblies
•
Internal removable scrap baskets and
two-piece scrap screens
•
Standard vertical opening accommodates
18" x 26" sheet pans
•
Wide 26" leakproof door, internally-fitted
•
Anti-jam conveyor drive system
•
Energy Sentinel (Idle pump shut-off)
•
Convenient top-mounted controls
•
Automatic tank fill
•
Common utility connections
•
Door safety switch
•
Door activated drain closure
•
Enclosure panels (front and sides)
•
Splash shields
•
Low-water tank heat protection
•
Rinse-saver device
•
Stainless steel heavy-gauge construction,
including base and feet
•
Electric tank heat
•
Wash pump 2 Hp motor
•
Stainless steel pump and impeller
•
Single-point electrical connection
The DualRinse feature offers the
Lowest Water/Utility/Chemical Consumption
circulating a generous
300+ gallons of water for
Consistently Good Results
Champion Industries, Inc.
2674 N. Service Road,
Jordan Station, Ontario, Canada L0R 1S0
Tel: 905/562-4195 Fax: 905/562-4618
(1M) 9/06 Printed in U.S.A.
Project
Item No.
Quantity
Model 44 dRWS
Shown with Vent Cowl
and Damper Option
SPeCIFIeR STaTeMeNT
Specified unit will be Champion Model 44 DRWS
water saver high temperature dual rinse rack conveyor
dishwashing machine. Constructed of Type 304
stainless steel and measuring 44" long with 20-3/4"
vertical opening. Features top mounted control
cabinet; upper and lower one-piece stainless steel
spray arm assemblies, removable internal scrap basket
while
with two-piece scrap screen. Large 26" wash door with
front access and double-hook safety latch. Anti-jam
conveyor drive system.
1 year parts and labor warranty.
44" Single Tank Water Saver
High Temperature Rack
Conveyor Dishwashing Machine with
Dual Stage Rinse
Champion Industries, Inc.
P. O. Box 4149, Winston-Salem, NC 27115
Tel: 336/661-1556 Fax: 336/661-1979
www.championindustries.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Model 44 DRWS and is the answer not in the manual?

Questions and answers

Related Manuals for Champion Model 44 DRWS

Summary of Contents for Champion Model 44 DRWS

  • Page 1 Conveyor Dishwashing Machine with Shown with Vent Cowl and Damper Option SPeCIFIeR STaTeMeNT Specified unit will be Champion Model 44 DRWS water saver high temperature dual rinse rack conveyor dishwashing machine. Constructed of Type 304 stainless steel and measuring 44” long with 20-3/4”...
  • Page 2 • Integrated design saves floor space leSS IS MoRe WITh ChaMPIoN’S dUal RINSe Model 44 dRWS Check our NSF listings and you’ll see the 44 DRWS offers the lowest water consumption in its class with less than .54 US gallons per rack. Water consumption this low means energy savings too. Our 40°F rise booster only requires 10 kW and 70°F rise is only 16 kW.
  • Page 3 (instead of standard 20-3/4”) for large ware Due to an ongoing value analysis program at Champion, specifications contained in this catalog are subject to change without notice. Champion Industries, Inc., P. O. Box 4149, Winston-Salem, NC 27115 • 336/661-1556 • Fax: 336/661-1979 • www.championindustries.com 2674 N.

  • Page 4: Front View

    2-1/4" 21" Suggested Table Construction Champion Industries, Inc., P. O. Box 4149, Winston-Salem, NC 27115 • 336/661-1556 • Fax: 336/661-1979 • www.championindustries.com 2674 N. Service Road, Jordan Station, Ontario, Canada L0R 1S0 • 905/562-4195 • Fax: 905/562-4618 12" Plumbing 7"...
  • Page 5 2-1/4" 21" Suggested Table Construction Champion Industries, Inc., P. O. Box 4149, Winston-Salem, NC 27115 • 336/661-1556 • Fax: 336/661-1979 • www.championindustries.com 2674 N. Service Road, Jordan Station, Ontario, Canada L0R 1S0 • 905/562-4195 • Fax: 905/562-4618 12" Plumbing 7"...

  • Page 6: Specifications

    480/60/3 575/60/3 Due to an ongoing value analysis program at Champion, specifications contained in this catalog are subject to change without notice. Champion Industries, Inc., P. O. Box 4149, Winston-Salem, NC 27115 • 336/661-1556 • Fax: 336/661-1979 • www.championindustries.com 2674 N. Service Road, Jordan Station, Ontario, Canada L0R 1S0 • 905/562-4195 • Fax: 905/562-4618 Table b - Machine &...
