Champion Model 66 WSPW Gas Specifications

66" gas heated water saver high-temperature rack conveyor dishwashing machine with prewash
Hide thumbs Also See for Model 66 WSPW Gas:
1
2
3
4

Advertisement

Quick Links

Download this manual
STANDARD FEATURES
• Dual-pawl cradle drive system
• One-piece cast stainless steel upper
& lower spray arm assemblies
• Internal removable scrap baskets with
two-piece scrap screens
• Standard vertical opening accommodates
18" x 26" sheet pans
• Wide 15-1/2" and 26" leakproof doors,
internally-fitted
• Anti-jam conveyor drive system
• Energy Sentinel (Idle pump shut-off)
• Convenient top-mounted controls
• Automatic tank fill
• Common utility connections
• Door safety switch
• Door activated drain closures
• Enclosure panels (front and sides)
• Splash shields
• Low-water tank heat protection
• Rinse-saver device
• Stainless steel heavy-gauge construction,
including base and feet
• Prewash pump 1 Hp motor
• External prewash scrap basket
• Wash pump 2 Hp motor
• Stainless steel pumps and impellers
• Single-point electrical connection
Single
Source
Gas Heating
Systems
(1M) 4/06
Printed in U.S.A.
Project
Item No.
Quantity
66 WSPW
Gas
Single-tank Dishwashing Machine with Prewash
SPECIFIER STATEMENT
Specified unit will be Champion model 66WSPW gas
heated water saver high temperature rack conveyor
single-tank dishwashing machine with prewash.
Features top mounted control cabinet; upper and lower
one-piece stainless steel spray arm assemblies, removable
internal scrap basket with two-piece scrap screen. Large
15-1/2" prewash and 26" wash and door with front access and
double-hook safety latch. Anti-jam conveyor drive system.
1 year parts and labor warranty.
P. O. Box 4149, Winston-Salem, NC 27115
Gas Heated Water Saver
High Temperature Rack Conveyor
Champion Industries, Inc.
Tel: 336/661-1556
Fax: 336/661-1979
www.championindustries.com
66"

Advertisement

loading
Need help?

Need help?

Do you have a question about the Model 66 WSPW Gas and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Champion Model 66 WSPW Gas

Summary of Contents for Champion Model 66 WSPW Gas

  • Page 1 66 WSPW High Temperature Rack Conveyor Single-tank Dishwashing Machine with Prewash SPECIFIER STATEMENT Specified unit will be Champion model 66WSPW gas heated water saver high temperature rack conveyor single-tank dishwashing machine with prewash. Features top mounted control cabinet; upper and lower one-piece stainless steel spray arm assemblies, removable internal scrap basket with two-piece scrap screen.
  • Page 2 A. 1-1/2 NPT machine connection. B. T/P relief valve to open drain C. 1/2" NPT vent to open drain 4 Vents (Dishwasher) (4" x 16" outside) A. Load end: 200 CFM @ 1/4" S.P. B. Unload end: 400 CFM @ 1/4" S.P. 5 Gas 3/4"...

  • Page 3: Specifications

    7-1/2" 2-3/4" Due to an ongoing value analysis program at Champion, specifications contained in this catalog are subject to change without notice. Champion Industries, Inc., P. O. Box 4149, Winston-Salem, NC 27115 • 336/661-1556 • Fax: 336/661-1979 • www.championindustries.com 66"...
  • Page 4 (instead of standard 20-3/4") for large ware Due to an ongoing value analysis program at Champion, specifications contained in this catalog are subject to change without notice. Champion Industries, Inc., P. O. Box 4149, Winston-Salem, NC 27115 • 336/661-1556 • Fax: 336/661-1979 • www.championindustries.com 66"...
